Installation

Control cabinet installation

Operating Instructions – MOVIDRIVE

modular

4.5.3 Installing shield plates

Bottom shield plate

[3]

[1]

[2]

20806998283

1. Install the shield plate [3] from below.

24748536/EN – 11/2017
