SEW-Eurodrive MOVIDRIVE MDA90A-0160-503-X-S00

6
Operation
Axis module fault
Operating Instructions – MOVIDRIVE
®
modular
188
6.5.19 Error 24 Cam switch
Subfault: 24.1
Description: Cam window limits interchanged
Response: Warning
Cause Measure
Left cam window limit larger than right limit Check cam window limits and adjust.
Subfault: 24.2
Description: Cam window limit not within modulo range
Response: Warning
Cause Measure
Cam window limits outside modulo range Check cam window limits and adjust.
Subfault: 24.3
Description: Cam windows of a track overlap
Response: Warning
Cause Measure
Cam window limits of a track overlap Adjust the cam window limits in such a way that they are flush.
6.5.20 Error 25 Parameter memory monitoring
Subfault: 25.2
Description: NV memory – runtime error
Response: Emergency stop + output stage inhibit
Cause Measure
Runtime error of the non-volatile memory system. – Reset device.
If this occurs repeatedly, replace device. Contact the SEW-
EURODRIVE Service.
Subfault: 25.6
Description: NV memory – incompatible data
Response: Emergency stop + output stage inhibit
Cause Measure
Incompatible data detected while reading non-volatile memory. The data on the (mobile) non-volatile memory might have been
formatted for another device. You can rectify the error by re-
formatting the data (basic initialization).
Subfault: 25.7
Description: NV memory initialization – error
Response: Emergency stop + output stage inhibit
Cause Measure
Error while initializing non-volatile memory system. – Reset device.
If this occurs repeatedly, replace device. Contact the SEW-
EURODRIVE Service.
Subfault: 25.10
Description: Power section configuration data – version conflict
Response: Emergency stop + output stage inhibit
Cause Measure
Wrong version of configuration data of power section. Contact the SEW-EURODRIVE Service.
Subfault: 25.12
Description: Power section configuration data – CRC error
Response: Emergency stop + output stage inhibit
Cause Measure
Faulty configuration data of power section. Contact the SEW-EURODRIVE Service.
Subfault: 25.13
Description: Control electronics configuration data – CRC error
Response: Emergency stop + output stage inhibit
Cause Measure
Faulty configuration data of control electronics. Contact the SEW-EURODRIVE Service.
24748536/EN – 11/2017
