Unit structure, axis system structure

Card slots

Operating Instructions – MOVIDRIVE

modular

3.9.2 Double-axis modules

MDD90A-0020, 0040 (size 1) MDD90A-0020, 0040, 0080 (BG 2)

X31X20_1X21_1

X20_2X21_2

X15_1

X15_2

RUN ERR

[1]

X31

X20_1X21_1

X20_2X21_2

X15_1

X15_2

RUN ERR

+UZ

24V

GND

-UZ

+ UZ- UZ

[1]

[2]

9007212170096139

[1] Connector panel of basic device for the first and second axis

[2] Safety card/additional encoder slot

24748536/EN – 11/2017
