Technical Data
Technical data of the cards
Operating Instructions – MOVIDRIVE
®
modular
233
Terminal designation/
specification
Specification
CIO21A CID21A
Assignment
X51:1
X51:4
Analog voltage output AOV2/AOV3
X51:2
X51:5
Analog current output AOC2/AOC3
X51: 3, 6 GND
Voltage output
Tolerance ± 5%
Capacitive load ≤ 300 nF
Inductive load < 500 μH
Load resistance ≥ 1kΩ
Resolution 12 bit
Reset state 0 V
Output value -10 V to +10 V, ≤ 10 mA
Current output
Tolerance ± 3%
Capacitive load ≤ 300 nF
Inductive load None
Load resistance ≤ 500Ω
Resolution 11 bit
Reset state 0 mA
Measuring range 0(4) – 20 mA
Reference voltage output
Short-circuit protection Yes
Output voltage DC -10 V, DC +10 V
Tolerance ± 0.5%
Noise ≤ 10 mA
Output current ≤ 3 mA
Capacitive load ≤ 300 nF
Inductive load < 500 μH
Assignment
X50: 1 REF1 (DC +10 V)
X50: 8 REF2 (DC -10 V)
INFORMATION
Freewheeling diode application
If inductive loads are connected to the digital outputs, you must install an external
protective element (freewheeling diode).
