Technical Data

Dimension sheets of the modules

Operating Instructions – MOVIDRIVE

®

modular

225

MDP90A-1100-..

(size 4)

424

29

63

673*

511

187*

286

180

486

7

19

13

210

455

9007218299154443

24748536/EN – 11/2017
