TheLEDwillshowthisstateiftheopenSPOT3isbroadcastingit'sownWi-FinetworkcalledopenSPOT3AP.
SeetheConnectingtheopenSPOT3toaWi-Finetworksectionforinformationonhowtoconnecttothis
accesspointandsetuptheopenSPOT3.
Ifyou'vepreviouslysetuptheopenSPOT3andwanttoswitchitbacktonormalmode,presstheWi-Fi
buttonfor3seconds.
Accesspoint(AP)modeactive,clientconnected:
TheLEDwillshowthisstateifyou'veconnectedyourbrowserdevice(phone/tablet/computer)tothe
openSPOT3'sownWi-FinetworkcalledopenSPOT3AP.
openSPOT3istryingtoconnecttoaWi-Finetwork:
ConnectingtoaWi-Finetworkshouldonlytake10-20seconds.IftheLEDisshowingthisstatefortoolong,
thenpleasemakesureyouareintherangeofapreviouslysetWi-Finetwork,orturnonAPmodeby
pressingtheWi-Fibuttonfor3seconds,andsetupanewWi-Ficonnectionagain.SeetheConnectingthe
openSPOT3toaWi-FinetworkinformationonhowtosetupaWi-FinetworkconnectioninAPmode.
Alsopleaserefertothetroubleshootingsectionforadditionalhelp.
openSPOT3isconnectedtotheWi-Finetworkandtryingtoconnecttotheselectedserver:
Connectingtoaservershouldonlytakeafewseconds.IftheLEDisshowingthisstatefortoolong,then
pleaseseemoreinformationintheTroubleshootingsection.
openSPOT3isconnectedtotheWi-Finetworkandaspecialconnectorisactive(ex.Nullconnectoror
AutoCal):
openSPOT3isconnectedtotheselectedserverandisstandingby:
LEDstates
