MX-2300/2700 N/G SIMULATION 7 – 57
* Change the page with [↓] or [↑] key.
* If there is a page over [↑], an active display is shown and the
page moves up. If there is no page upward, the display
grays out and the operation is invalid.
If there is a page under [↓], an active display is shown and
the page moves down. If there is no page downward, the
display grays out and the operation becomes invalid.
2) When [NEXT] button is pressed, data of another category are
displayed.
* When [NEXT] button is pressed on the last category data
display, the data of the first category are displayed.
* When [NEXT] button is pressed, the data of the next cate-
gory are displayed regardless of the display page.
* When [CLOSE] button is pressed, the display shifts to the
copy basic screen of simulation.
* Copying can be performed also by pressing [COLOR]/
[BLACK] key.
<Display item and content description>
<Toner density> * Common to KCMY
<Details of toner density sensor reference value correction>
* Common to KCMY
<Details of toner density sensor control voltage correction>
* Common to KCMY
* When the correction for the developer counter (life) or the humidity correction is inhibited (OFF) in SIM 44-01, the correction level is dis-
played as "0."
<Display of current humidity area and that in auto developer adjustment>
* Common to KCMY
Display item Item content
Set
range
Default
value
TONER
DEN_LT(M)
Current toner density sensor
output value (final value) at
middle speed
1 to 255 129
TONER
DEN_ST(M)
Current toner density reference
value (including all the correction
values) at middle speed
128
TONER
DEN_LT(L)
Current toner density sensor
output value (final value) at low
speed
129
TONER
DEN_ST(L)
Current toner density reference
value (including all the correction
values) at low speed
128
Display item Item content Content description
Set
range
Default
value
AUTO DEVE (M) Automatic developer adjustment value (at
middle speed)
Sensor output value after execution of SIM 25-02 (at middle speed) 1 to 255 128
ALL(M) All correction reference value (at middle
speed)
Correction reference value (at middle speed) used to calculate all the
correction values for auto developer adjustment value
AUTO DEVE (L) Automatic developer adjustment value (at
low speed)
Sensor output value after execution of SIM 25-02 (at low speed)
ALL(L) All correction reference value (at low
speed)
Correction reference value (at low speed) used to calculate all the
correction values for auto developer adjustment value
AREA Area correction value Correction value for environment area –127 to
127
0
HUD Humidity correction value Correction value for humidity change
PRINT RATE Print rate correction value Correction value for document print rate
PROCON Process control correction value Correction value for high density process control result
LIFE Life correction value Correction value for developer life
SENSITIVITY Sensitivity correction value Correction for toner density sensor sensitivity 1 to 999 500
Display item Item content Content description
Set
range
Default
value
AUTO DEVE VO(M) Automatic developer adjustment control
voltage (at middle speed)
Sensor control voltage value (at middle speed) after executing SIM
25-02
1 to 255 128
ALL VO(M) All correction reference control voltage (at
middle speed)
Control voltage reference value (at middle speed) used to calculate all
the correction values for auto developer adjustment value
AUTO DEVE VO(L) Automatic developer adjustment control
voltage (at low speed)
Sensor control voltage value (at low speed) after executing SIM 25-02
ALL VO(L) All correction reference control voltage (at
low speed)
Control voltage reference value (at low speed) used to calculate all
the correction values for auto developer adjustment value
AREA VO Area correction control voltage Control voltage correction value for environment area –127 to
127
0
HUD VO Humidity correction control voltage Control voltage correction value for humidity change
PRINT RATE VO Print rate correction control voltage Control voltage correction value for document print rate
PROCON VO Process control correction control voltage Control voltage correction value for high density process control result
LIFE VO Life correction control voltage Control voltage correction value for developer life
SENSITIVITY VO Sensitivity correction control voltage Control voltage correction value for toner density sensor sensitivity 1 to 999 500
ENV VO Environment correction control voltage Control voltage correction value under high temperature environment –127 to
127
0
Display item Item content Content description
Set
range
Default
value
AUTO DEVE AREA Auto developer adjustment area Auto developer adjustment humidity area display 1 to 14 8
AREA Current area Current humidity area display
