Sharp MX-2300 G

MX-2300/2700 N/G MAINTENANCE 9 – 7
D. Transfer section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the Parts Guide.
Block/Item No.
(Only the replacement parts are
described.)
1 Intermediate
transfer belt
Mechanical
parts
✕ ▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [26]-3)
2 Primary transfer
roller
✕✕✕▲✕✕▲✕✕▲✕✕▲(P/G No.: [27]-9)
(P/G No.: [28]-27)
3 Intermediate
transfer blade
✕ ▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [25]-19)
4 Belt drive gear ✕ ▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [27]-13)
5 Primary transfer
conduction collar
✕ ▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [27]-8)
(P/G No.: [28]-25)
6 Transfer drive roller {{{{{{{{{ { { {
7 Transfer follower
roller
{{{{{{{{{ { { {
8 Tension roller {{{{{{{{{ { { {
9 Belt CL brush ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
10 Y auxiliary roller {{{{{{{{{ { { {
11 Resist backup roller ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
12 Secondary transfer
belt
✕✕✕▲✕✕▲✕✕▲✕✕▲(P/G No.: [30]-21)
13 Secondary transfer
roller
✕✕✕▲✕✕▲✕✕▲✕✕▲(P/G No.: [30]-6)
14 Secondary belt
drive roller
✕✕{ ✕✕{ ✕✕{ ✕✕{
15 Secondary belt
tension roller
✕✕{ ✕✕{ ✕✕{ ✕✕{
16 Secondary belt
follower roller
✕✕{ ✕✕{ ✕✕{ ✕✕{
17 Secondary transfer
idle gear
✕✕✕▲✕✕▲✕✕▲✕✕▲(P/G No.: [29]-6)
18 Sensors (Process
control resist
sensors)
✕ {{{{{{{{{ { { {
19 Primary CL roller ▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [26]-56)
20 Cleaner seal ✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
21 Cleaner seal R ✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
22 Transfer toner
reception seal
✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
5
1
4
21
12
17
10
8
8
7
7
6
15
16
14
15
13,17
16
4,6
10
2,5
11
9
3
13
11
9
14
2
3
18
19
20
19
