Sharp MX-2300 G

MX-2300/2700 N/G SPECIFICATIONS 2 – 1
MX2700N
Service Manual
[2] SPECIFICATIONS
1. Basic specifications
A. Base engine
(1) Type
(2) Engine speed
a. Tray1 – 4 (Main unit), LCC
b. Manual (Main unit)
*1: Switched by the service simulation setting
(3) Engine composition
(4) Shifter
(5) Engine resolution
(6) Warmup
(7) Jam recovery time
(8) Printable area
* The printable area for 12 x 18 must be as large as the A3/11 x 17
page dimension by PCL / PS driver.
(9) Void area
Type Desk-top
Color support Full color
Paper size
MX-2700G/N MX-2300G/N
B/W Color B/W Color
A3, 11 x 17, 8K 14 14 12 12
B4, 8.5 x 14, 8.5 x 13 16 16 14 14
A4, B5, 8.5 x 11, 16K 27 27 23 23
A4R, B5R, A5R, 8.5 x 11R,
7.25 x 10.5R, 5.5 x 8.5R, 16KR
19 19 16 16
Extra 13 13 11 11
Paper size
MX-2700G/N MX-2300G/N
B/W Color B/W Color
A3, 11 x 17, 8K 14 11 12 11
B4, 8.5 x 14, 8.5 x 13 16 12 14 12
A4, 8.5 x 11, 16K 23 21 23 21
B5 23 23 23 23
A4R, 16KR 19 14 16 14
8.5 x 11R 19 15 16 15
B5R, 7.25 x 10.5R 19 16 13 13
A5R, 5.5 x 8.5R 19 19 19 19
12 x 1 8 13 11 11 11
OHP(A4, 8.5 x 11) 11 10 11 10
OHP(A4R, 8.5 x 11R) 9 7 9 7
Extra 13111111
Envelope 13 13 11 11
Heavy paper (B5, A4, A5R, 8.5 x 11,
8.5 x 5.5R, 16K)
11 10 11 10
Heavy paper (Postcard HIGH)*1 11 10 11 10
Heavy paper (Postcard LOW)*1 7 7 7 7
Heavy paper (Other sizes) 7 5 7 5
Photoconductor kind OPC (Drum diameter: Black; φ30mm, Color;
φ30mm x 3)
Copying method Electronic photo (Laser)
Developing system Dry-type dual-component magnetic brush
development
Charging system Charged saw-tooth method
Transfer system Intermediate transfer belt
Cleaning system Counter blade
Fusing system Heat roller
Waste toner disposal No toner recycling system
Type Shifter
Paper weight 55 – 209g/m
2
(17 – 56 lbs)
Paper size Non offset
mode
(Normal
output)
A3, B4, A4R, B5, B5R, A5R, Postcard, 8K,
16K, 16KR,11 x 17, 8.5 x 14, 8.5 x 13,
8.5 x 11, 8.5 x 11R, 7.25 x 10.5R,
5.5 x 8.5R, Envelope, Extra
Offset
mode
A3, B4, A4R, B5, B5R, A5R, Postcard, 8K,
16K, 16KR, 11 x 17, 8.5 x 14, 8.5 x 13,
8.5 x 11, 8.5 x 11R, 7.25 x 10.5R, 5.5 x
8.5R (Not Envelope, Extra)
Productivity
(A4, 8.5x11)
Non-offset
(Normal
output)
MX-2300G/N B/W 23cpm
Color 23cpm
MX-2700G/N B/W 27cpm
Color 27cpm
Offset
mode
MX-2300G/N B/W 23cpm
Color 23cpm
MX-2700G/N B/W 27cpm
Color 27cpm
Offset range 30mm
Range of error
(In using the
recommended
paper, A4/8.5
x 11)
Horizontal
direction
Vertical
direction
Between
Jobs
Non-offset Not drop from
the tray.
--
Offset
mode
Within 50mm Within
±10mm
Min.10mm
Resolution Writing:
600 x 600dpi
1200 x 600dpi (Monochome printing only.)
* Rotation output not allowed at 1200dpi x 600dpi. PS
expansion kit needed.
Smoothing
function
None
Gradation Writing:
Monochrome: 2 levels (1bit) / Equivalent of 256 steps
Color: Each color 2 levels (1bit) / Each color 16 levels
(4bits) / Equivalent of 256 steps
Warmup time 80 sec or less
* The value may be increased if process-control
processing is being executed. Same as current model
Pre-heat Yes
With the door
open
Approx.
60 sec
Condition: After the door is kept open for 60
seconds, standard setting, the polygon
motor halt
A3 293 x 413mm 12 x 18 * 279 x 432mm
B4 253 x 357mm 11 x 17 275 x 425mm
A4 206 x 290mm 8.5 x 14 212 x 349mm
B5 178 x 250mm 8.5 x 13 212 x 323mm
A5 144 x 203mm 8.5 x 11 212 x 272mm
7.25 x 10.5 180 x 260mm 5.5 x 8.5 136 x 209mm
Postcard 96 x 141mm 8K 266 x 383mm
16K 191 x 263mm
Void area
Image loss
Top: 4 mm or less
Bottom: 3 mm or less
FR Total: 4 mm or less
