Sharp MX-2300 G

MX-2300/2700 N/G MAINTENANCE 9 – 11
H. Paper feed section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the Parts Guide.
Block/Item No.
(Only the replacement parts are
described.)
1 Pickup roller Mechanical
parts
{ {{{{{{{{{ { { {(P/G No.: [11]-40, [16]-33)
2 Paper feed roller { {{{{{{{{{ { { {(P/G No.: [11]-41, [16]-29)
3 Separation roller { {{{{{{{{{ { { {(P/G No.: [10]-4, [15]-37)
4 Torque limiter ✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
1
4
4
1
4
2
3
2
3
1
2
3
