MX-2300/2700 N/G TRAY PAPER FEED SECTION E – 8
4. Maintenance
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shif the position.
No. Parts name
Monochrome
supply,
mechanical
parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the
Parts Guide.
Block/Item No. (Only
the replacement parts
are described.)
1 Pickup roller Mechanism
parts
{ {{{{{{{{{ { { {(P/G No.: [11]-40)
2 Paper feed roller { {{{{{{{{{ { { {(P/G No.: [11]-41)
3 Separation roller { {{{{{{{{{ { { {(P/G No.: [10]-4)
4 Torque limiter ✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
5 Transport rollers { {{{{{{{{{ { { {
1
4
4
2
3
1
2
3
5
5
