MX-2300/2700 N/G OTHERS 12 – 6
*1: In some countries and regions, the printer expansion kit must be
installed.
*2: This function is not available in some countries and regions.
*3: When an automatic document feeder is installed.
*4: In some countries and regions, the network scanner expansion
kit must be installed.
*5: When the Internet fax expansion kit is installed.
*6: When the facsimile expansion kit is installed.
*7: When a large capacity tray is installed.
*8: When a paper drawer is installed.
*9: When a saddle stitch finisher or finisher is installed.
*10: When a saddle stitch finisher is installed.
*11: When a punch module is installed.
*12: When a colour-related problem has occurred.
*13: When the PS3 expansion kit is installed.
*14: In some countries and regions, the facsimile expansion kit or
the Internet fax expansion kit or the network scanner expansion kit
must be installed.
*15: When network connection is enabled.
*16: When a right tray is installed.
*17: When the application integration module is installed.
*18: Depending on the peripheral devices installed, it may not be
possible to use some settings.
2. Paper JAM code
A. JAM cause code list
(1) PCU JAM cause
● Internet Fax Expansion Kit -
● E-mail Alert and Status -
● Application Integration Module -
● Serial Number -
■ Storing/calling of System Settings
● Restore Factory Defaults -
● Store Current Configuration -
● Restore Configuration -
Code Code content
NO_JAM_CAUSE No JAM. Also used for JAM canceling.
NO_MATCH Parameter no matching
STOP_JAM Emergency stop request JAM (Controller request)
TRAY1 Cassette 1 paper feed JAM (CPFD1 not-reached
JAM)
CPFD1_S1 CPFD1 remaining JAM (Cassette 1 feed paper)
CPFD1_N2 CPFD1 not-reached JAM (Cassette 2 feed paper)
CPFD1_N3 CPFD1 not-reached JAM (Desk 1 feed paper)
CPFD1_N4 CPFD1 not-reached JAM (Desk 2 feed paper)
CPFD1_S2 CPFD1 remaining JAM (Desk 2 feed paper)
CPFD1_S3 CPFD1 remaining JAM (Desk 1 feed paper)
CPFD1_S4 CPFD1 remaining JAM (Desk 2 feed paper)
TRAY2 Cassette 2 paper feed JAM (CPFD2 not-reached
JAM)
CPFD2_N3 CPFD2 not-reached JAM (Desk 1 feed paper)
CPFD2_N4 CPFD2 Not-reached JAM (Desk 2 feed paper)
CPFD2_S2 CPFD2 remaining JAM (Cassette 2 feed paper)
CPFD2_S3 CPFD2 remaining JAM (Desk 1 feed paper)
CPFD2_S4 CPFD2 remaining JAM (Desk 2 feed paper)
PPD1_N1 PPD1 not-reached JAM (Cassette 1 feed paper)
PPD1_N2 PPD1 not-reached JAM (Cassette 2 feed paper)
PPD1_N3 PPD1 not-reached JAM (Desk 1 feed paper)
PPD1_N4 PPD1 not-reached JAM (Desk 2 feed paper)
PPD1_NM PPD1 not-reached JAM (Manual feed tray feed
paper)
PPD1_NL PPD1 not-reached JAM (Side LCC feed paper)
PPD1_NA PPD1 not-reached JAM (ADU refeed paper)
PPD1_S1 PPD1 remaining JAM (Cassette 1 feed paper)
PPD1_S2 PPD1 remaining JAM (Cassette 2 feed paper)
Item Factory default setting
PPD1_S3 PPD1 remaining JAM (Desk 1 feed paper)
PPD1_S4 PPD1 remaining JAM (Desk 2 feed paper)
PPD1_SM PPD1 remaining JAM (Manual 2 feed paper)
PPD1_SL PPD1 remaining JAM (Side LCC feed paper)
PPD1_SA PPD1 remaining JAM (ADU refeed paper)
PPD2_N1 PPD2 not-reached JAM (Cassette 1 feed paper)
PPD2_N2 PPD2 not-reached JAM (Cassette 2 feed paper)
PPD2_N3 PPD2 not-reached JAM (Desk 1 feed paper)
PPD2_N4 PPD2 not-reached JAM (Desk 2 feed paper)
PPD2_NM PPD2 not-reached JAM (Manual feed tray feed
paper)
PPD2_NL PPD2 not-reached JAM (Side LCC feed paper)
PPD2_NA PPD2 not-reached JAM (ADU refeed paper)
PPD2_S1 PPD2 remaining JAM (Cassette 1 feed paper)
PPD2_S2 PPD2 remaining JAM (Cassette 2 feed paper)
PPD2_S3 PPD2 remaining JAM (Desk 1 feed paper)
PPD2_S4 PPD2 remaining JAM (Desk 2 feed paper)
PPD2_SM PPD2 remaining JAM (Manual feed tray feed paper)
PPD2_SL PPD2 remaining JAM (Side LCC feed paper)
PPD2_SA PPD2 remaining JAM (ADU refeed paper)
PPD2_PRI PPD2 JAM (Image preparation wait timeout)
POD1_N POD1 not-reached JAM
POD1_S POD1 remaining JAM
POD2_N POD2 not-reached JAM
POD2_S POD2 remaining JAM
POD3_N POD3 not-reached JAM
POD3_S POD3 remaining JAM
APPD1_N APPD1 not-reached JAM
APPD1_S APPD1 remaining JAM
APPD2_N APPD2 not-reached JAM
APPD2_S APPD2 remaining JAM
TRAY3 Cassette 3 (Desk 1) paper feed JAM
DPFD1_N4 DPFD1 not-reached JAM (Desk 2 feed paper)
DPFD1_S3 DPFD1 remaining JAM (Desk 1 feed paper)
DPFD1_S4 DPFD1 remaining JAM (Desk 2 feed paper)
TRAY4 Cassette 4 (Desk 2) paper feed JAM
DPFD2_S4 DPFD2 remaining JAM (Desk 2 feed paper)
MFT Manual feed tray paper feed JAM (MPFD not-
reached)
MPFD_S MPFD remaining JAM (Manual feed tray feed paper)
LCC Side LCC paper feed JAM (LPFD1 not-reached)
LPFD_SL LPFD remaining JAM (Side LCC feed paper)
SIZE_ILG Size illegal JAM
MTR_ILG Motor driver trouble JAM
FJPID_N Interface transport inlet port sensor not-reached JAM
FJPID_S Interface transport inlet port sensor remaining JAM
FJPOD_N Interface transport outlet sensor not-reached JAM
FJPOD_S Interface transport outlet sensor remaining JAM
FED_N Finisher inlet port sensor not-reached JAM
FED_S Finisher inlet port sensor remaining JAM
FFPD_N Finisher saddle not-reached JAM
FFPD_S Finisher saddle remaining JAM
FEXIT_S Finisher bundle exit remaining JAM
FSTPL Staple JAM
FPNCH Punch JAM
FDOP Finisher door open
FIN_TIME Finisher paper clearance abnormality JAM
Code Code content
