Sharp MX-2300 G

MX-2300/2700 N/G MAINTENANCE 9 – 6
C. Developing section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the Parts Guide.
Block/Item No.
(Only the replacement parts are
described.)
Color supply 60
K
120
K
180
K
240
K
300
K
360
K
1 Developer (BK) Monochrome
supply
▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲
2 DV seal (BK) ▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [23]-42)
3 DV side seal F
(BK)
▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [23]-26)
4 DV side seal R
(BK)
▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [23]-15)
5 Toner filter ▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [22]-37)
6 Developer (C) Color supply ▲▲▲▲ ▲ ▲
7 Developer (M) ▲▲▲▲ ▲ ▲
8 Developer (Y) ▲▲▲▲ ▲ ▲
9 DV seal (C) ▲▲▲▲ ▲ ▲(P/G No.: [23]-42)
10 DV side seal F/R
(C)
▲▲▲▲ ▲ ▲(P/G No.: [23]-26, [23]-15)
11 Toner filter ▲▲▲▲ ▲ ▲(P/G No.: [22]-37)
12 Toner cartridge
(BK/C/M/Y)
Monochrome/
Color supply
User replacement for every toner empty (or the specified traveling distance).
13 Bias pin/
Connector
Mechanical
parts
✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
1,6,7,8
2,9
13
13
3,10
4,10
5,11
13
12
