MX-2300/2700 N/G SIMULATION 7 – 20
22
22-1
Purpose : Adjustment/Setup/Operation data check
Function (Purpose) : Used to check the print count value in each
section and each operation mode. (Used to
check the maintenance timing.)
Section :—
Item : Counter
Operation/Procedure
Change the display page with [↑] [↓] buttons.
Press [COLOR] or [BLACK] button to print.
22-2
Purpose : Adjustment/Setup/Operation data check
Function (Purpose) : Used to check the total numbers of misfeed
and troubles. (When the number of total
jam is considerably great, it is judged as
necessary for repair.)
Section :—
Item : Counter
Operation/Procedure
The paper jam/trouble counter value is displayed.
Press [COLOR] or [BLACK] button to print.
22-3
Purpose : Adjustment/Setup/Operation data check
Function (Purpose) : Used to check misfeed positions and the
misfeed count of each position.
Section :—
Item : Trouble
Operation/Procedure
The history of paper jams and misfeed is displayed.
The above histories are displayed from the newest one to the old-
est in this sequence. The max. 50 items are saved. (The oldest one
is sequentially erased.)
* List of JAM codes: Refer to "2. Paper JAM code" in the "[12]
OTHERS."
TOTAL OUT(BW) Total output quantity of black
TOTAL OUT(COL) Total output quantity of color
TOTAL(BW) Total use quantity of black
TOTAL(COL) Total use quantity of color
TOTAL(2COL) Total use quantity of 2-color
TOTAL(SGL_COL) Total use quantity of single color
COPY(BW) Black copy counter
COPY(COL) Color copy counter
COPY(2COL) 2-color copy counter
COPY(SGL_COL) Single color copy counter
PRINT(BW) Black print counter
PRINT(COL) Color print counter
DOC FIL(BW) Black document filing print counter
DOC FIL(COL) Color document filing print counter
DOC FIL(2COL) 2-color document filing print counter
DOC FIL(SGL COL) Single-color document filing print counter
OTHER(BW) Black other counter
OTHER(COL) Color other counter
MAINTENANCE ALL Maintenance counter (Total)
MAINTENANCE COL Maintenance counter (Color)
TC1 BELT Primary transfer unit print counter
TC1 BELT RANGE Primary transfer unit accumulated traveling
distance (cm)
TC1 BELT DAY Use day of primary transfer (Day)
TC2 BELT Secondary transfer unit print counter
TC2 BELT RANGE Secondary transfer unit accumulated traveling
distance (cm)
TC2 BELT DAY Use day of secondary transfer unit (Day)
FUSER UNIT Fuser unit print counter
FUSER ACUM DAY Use day of fuser unit (Day)
DRUM LIFE(K) Accumulated number of drum rotations (K)
DRUM LIFE(C) Accumulated number of drum rotations (C)
DRUM LIFE(M) Accumulated number of drum rotations (M)
DRUM LIFE(Y) Accumulated number of drum rotations (Y)
DEVE LIFE(K) Accumulated number of developer rotations (K)
DEVE LIFE(C) Accumulated number of developer rotations (C)
DEVE LIFE(M) Accumulated number of developer rotations (M)
DEVE LIFE(Y) Accumulated number of developer rotations (Y)
0
A
A: 0
B: 0
; MAINTENANCE COUNTER (TOTAL)
; MAINTENANCE COUNTER (COLOR)
SIMULATION NO.21-01
MAINTENANCE CYCLE SETUP
0
[ 1~300]
OK
TEST
CLOSE
MACHINE JAM Machine JAM counter
RSPF/DSPF JAM SPF JAM counter
TROUBLE Trouble counter
TOTAL OUT(BW)
SIMULATION NO.22-01
TEST
COUNTER DISPLAY
CLOSE
TOTAL(SGL_COL)
TOTAL OUT(COL) COPY(BW)
TOTAL(BW) COPY(COL)
TOTAL(COL) COPY(2COL)
TOTAL(2COL)
: 00000000
: 00000000
: 00000000
: 00000000
: 00000000
: 00000000
: 00000000
: 00000000
: 00000000
: 00000000COPY(SGL_COL)
1/3
0
MACHINE JAM
SIMULATION NO.22-02
TEST
JAM/TROUBLE COUNTER DISPLAY
CLOSE
RSPF/DSPF JAM
TROUBLE
: 00000000
: 00000000
: 00000000
1/1
0
0
CLOSE
JAM HISTORY DATA DISPLAY
1/1
SIMULATION NO.22-03
TEST
1/1
PPD2_N1 CPFD2_S2 MFT TRAY3
PPD2_N1 CPFD2_S2 APPD3_S DPFD2_S4
LCC PPD2_PRI CPID2_S2 CPID2_S2
CPFD1_N1 PPD2_PRI TRAY3 APPD3_S
TRAY2 MFT
To Next Page
