Sharp MX-2300 G

MX-2300/2700 N/G SIMULATION 7 – 19
14
14--
Purpose : Clear/cancel (Trouble etc.)
Function (Purpose) : Used to cancel excluding the self-diag U1/
LCC/U2/PF troubles.
Section :—
Item : Trouble
Operation/Procedure
1) Press [EXECUTE] button.
2) Press [YES] button to execute cancellation of the trouble.
15
15--
Purpose : Clear/cancel (Trouble etc.)
Function (Purpose) : Used to cancel the self-diag "U6-09" (large
capacity paper feed tray) trouble.
Section :LCC
Item : Trouble
Operation/Procedure
1) Press [EXECUTE] button.
2) Press [YES] button to execute cancellation of the trouble.
16
16--
Purpose : Clear/cancel (Trouble etc.)
Function (Purpose) : Used to cancel the self-diag U2 trouble.
Section : MFPcnt PWB / PCU PWB / SCU PWB
Item : Trouble
Operation/Procedure
1) Press [EXECUTE] button.
2) Press [YES] button to execute cancellation of the trouble.
17
17--
Purpose : Clear/cancel (Trouble etc.)
Function (Purpose) : Used to cancel the self-diag PF.
Section : Communication unit (RIC/MODEM)
Item : Trouble
Operation/Procedure
1) Press [EXECUTE] button.
2) Press [YES] button to execute cancellation of the trouble.
21
21-1
Purpose :Setting
Function (Purpose) : Used to set the maintenance cycle.
Section :—
Item : Specifications
Operation/Procedure
1) Select an item corresponding to the set contents with [↑] [↓]
buttons.
2) Enter the value corresponding to the maintenance timing with
10-key.
3) Press [OK] button to save the entered conditions in step 2).
0
SI MU LA TI O N  NO.14
TEST
TROUBLE CANCELLATION(OTHER)
CLOSE
EXECUTE
ARE YO U S U RE?
YE
S
N
O
0
SIMULATI ON  NO.15
TEST
LCC TROUBLE CANCELLATION
CLOSE
EXECUTE
ARE YO U SURE?
YES NO
Item Display Content Set range
Default
value
A MAINTENANCE
COUNTER
(TOTAL)
Maintenance
counter
(total)
0: DEFAULT,
1 – 300: 1K – 300K
999: FREE
100K
B MAINTENANCE
COUNTER
(COLOR)
Maintenance
counter
(color)
0: DEFAULT,
1 – 300: 1K – 300K
999: FREE
60K
0
SIMULATION  NO.16
TEST
U2 TROUBLE CANCELLATION
CLOSE
EXECUTE
ARE YOU SURE?
YES NO
0
SIMULATION NO.17
TEST
PF TROUBLE CANCELLATION
CLOSE
EXECUTE
ARE YOU SURE?
YES NO
