Sharp MX-2300 G

MX-2300/2700 N/G SIMULATION 7 – 18
9
9-2
Purpose : Operation test/check
Function (Purpose) : Used to check the operations of the sen-
sors and detectors in the duplex section
and its control circuit.
Section : Duplex
Item : Operation
Operation/Procedure
The sensor and detector operation conditions are displayed.
The active sensors and detectors are highlighted.
9-3
Purpose : Operation test/check
Function (Purpose) : Used to check the operations of the loads
in the duplex section and the control cir-
cuits.
Section : Duplex
Item : Operation
Operation/Procedure
1) Select the item to be operation tested with the buttons on the
touch panel.
2) Press [EXECUTE] button.
The selected load operation is performed.
When [EXECUTE] button is pressed, the output is terminated.
10
10-1
Purpose : Operation test/check
Function (Purpose) : Used to check the operations of the toner
motor and the related circuit.
Section : Process (Developing)
Item : Operation
Operation/Procedure
* Before execution of this simulation, remove the toner cartridges.
1) Select the item to be checked with the buttons on the touch
panel.
2) Press [EXECUTE] button.
* The selected load operation is performed for 10 sec.
* When [EXECUTE] button is pressed, the operation is termi-
nated.
13
13--
Purpose : Clear/cancel (Trouble etc.)
Function (Purpose) : Used to cancel the self-diag "U1" trouble.
Section :FAX
Item : Trouble
Operation/Procedure
1) Press [EXECUTE] button.
2) Press [YES] button to execute cancellation of the trouble.
DSW_ADU ADU transport open/close detection
APPD1 ADU transport path detection 1
APPD2 ADU transport path detection 2
ADUM_L ADU motor lower
0
ADU SENSOR CHECK
1/1
CLOSE
SIMULATIO N  NO.09 㧙 02
TEST
1/1
DSW_ADU
APPD1 APPD2
0
SIMULATI ON  NO.09-03
TEST
ADU LOAD CHECK
EXECUTE
1/1
ADUM_L
CLOSE
TNM_K Toner motor K
TNM_C Toner motor C
TNM_M Toner motor M
TNM_Y Toner motor Y
0
SIMULATION  NO.10-01
TEST
TONER MOTOR ACTIVATION
EXECUTE
1/1
TNM_K
CLOSE
TNM_C
TNM_M
TNM_Y
0
SIMULATI O N  NO.13
TEST
U1 TROUBLE CANCELLATION
CLOSE
EXECUTE
ARE YOU SURE?
YES NO
