Sharp MX-2300 G

MX-2300/2700 N/G MAINTENANCE 9 – 3
2. Details of maintenance
A. Drum peripheral
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the Parts Guide.
Block/Item No.
(Only the replacement parts are
described.)
Color supply 60
K
120
K
180
K
240
K
300
K
360
K
1 Drum (BK) Monochrome
supply
▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲
2 Cleaner blade
(BK)
▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [24]-14)
3 Charging unit
(BK)
▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [24]-2)
4 Drum (C) Color supply ▲▲▲▲ ▲ ▲
5 Cleaner blade (C) ▲▲▲▲ ▲ ▲(P/G No.: [24]-14)
6 Charging unit (C) ▲▲▲▲ ▲ ▲(P/G No.: [24]-2)
7 Side seal F/R
(BK)
Mechanical
parts
✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
8 Toner reception
seal (BK)
✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
9 Side seal F/R(C) ✕✕✕✕ ✕ ✕
10 Toner reception
seal (C)
✕ ✕✕✕✕ ✕ ✕
11 Waste toner box ✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
3,6
7,9
8,10
2,5
7,9
1,4
11
