Sharp MX-2300 G

MX-2300/2700 N/G MAINTENANCE 9 – 13
J. Drive section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the Parts
Guide.
Block/Item No.
(Only the replacement
parts are described.)
1 Gears (Grease) Mechanical
parts
✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕HANARL FL955R/FLOIL
G313S
When checking, apply to
the necessary positions
(specified positions).
2 Shaft earth sections
(Conduction grease)
✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕When checking, apply to
the necessary positions
(specified positions).
3Belts ✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
2
1
3
1
(FLOIL G313S)
(HANARL FL955R)
