Sharp MX-2300 G

MX-2300/2700 N/G FAN AND FILTER SECTION R – 3
2. Maintenance
A. Filters
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shif the position.
No. Parts name
Monochrome
supply,
mechanical parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the
Parts Guide.
Block/Item No. (Only
the replacement parts
are described.)
1 Ozone filter PA ✕ ▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [47]-40)
1
