MX-2300/2700 N/G CONSUMABLE PARTS 3 – 3
2. Maintenance parts list
A. U.S.A/Canada/South and Central America/Asia/Middle East/Agencies
B. Europe/UK/Australia/New Zealand/Taiwan
No. Item Content Life Model name Remarks
1 Heat roller kit Upper heat roller x 1 200K MX-270HK
Fuser gear x 1
Upper separation pawl x 4
Upper thermistor sub x 1
Upper heat roller bearing x 2
Lower heat roller x 1
Lower thermistor x 1
Lower heat roller bearing x 2
2 Primary transfer kit Intermediate transfer belt x 1 100K MX-270Y1
Primary transfer blade x 1
Primary transfer conductive collar x 4
Transfer cleaning roller x 1
PS paper dust removal cleaner x 1
3 Secondary transfer kit Secondary transfer belt x 1 300K MX-270Y2
Secondary transfer roller x 1
Secondary drive idle gear x 1
Upper thermistor x 1
Primary transfer roller x 4
Belt drive gear x 1
4 Filter kit Ozone filter PA x 1 100K MX-270FL
5 Waste toner box kit Waste toner box unit (with LSU cleaner x 3) x 1 50K MX-270HB Each color 5% coverage, color
ratios 25%
6 DV seal kit DV seal x 3 Black: 100K,
Color: 60K
MX-270DS
DV side seal F/R x 3
Toner filter x 3
7 Staple cartridge Staple cartridge x 3 5000 times AR-SC2 For saddle finisher
8 Staple cartridge Staple cartridge x 3 5000 times MX-SCX1 For inner finisher
9 Primary transfer belt unit For service rotation x 1 MX-270U1
10 Secondary transfer belt unit For service rotation x 1 MX-270U2
11 Fusing unit For service rotation (Heater lamp 120V) x 1 MX-270FU1
For service rotation (Heater lamp 230V) x 1 MX-270FU
No. Item Content Life Model name Remarks
1 Upper heat roller kit Upper heat roller x 1 200K MX-270UH
Fuser gear x 1
Upper separation pawl x 4
Upper thermistor sub x 1
Upper heat roller bearing x 2
2 Lower heat roller kit Lower heat roller x 1 200K MX-270LH
Lower thermistor x 1
Lower heat roller bearing x 2
3 Primary transfer kit Intermediate transfer belt x 1 100K MX-270B1
Primary transfer blade x 1
Primary transfer conductive collar x 4
Transfer cleaning roller x 1
PS paper dust removal cleaner x 1
4 Primary transfer roller kit Primary transfer roller x 4 300K MX-270X1
Belt drive gear x 1
5 Secondary transfer belt kit Secondary transfer belt x 1 300K MX-270B2
6 Secondary transfer roller kit Secondary transfer roller x 1 300K MX-270X2
Secondary drive idle gear x 1
Upper thermistor x 1
7 Filter kit Ozone filter PA x 1 100K MX-270FL
8 Waste toner box kit Waste toner box unit (with LSU cleaner x3) x 1 50K MX-270HB Each color 5% coverage, color
ratios 25%
9 DV seal kit DV seal x 3 Black: 100K,
Color: 60K
MX-270DS
DV side seal F/R x 3
Toner filter x 3
10 Staple cartridge Staple cartridge x 3 5000 times AR-SC2 For saddle finisher
11 Staple cartridge Staple cartridge x 3 5000 times MX-SCX1 For inner finisher
12 Primary transfer belt unit For service rotation x 1 MX-270U1
13 Secondary transfer belt unit For service rotation x 1 MX-270U2
14 Fusing unit For service rotation (Heater lamp 230V) x 1 MX-270FU
For service rotation (Heater lamp 100V) x 1 MX-270FU2
