MX-2300/2700 N/G PAPER EXIT SECTION O – 1
MX2700N
Service Manual
[O] PAPER EXIT SECTION
1. Electrical and mechanism relation diagram
Signal name Name Function/Operation
FUM Fusing drive motor Drives the fusing unit.
HOPS Shifter home position detection Detects the shifter home position.
OSM Shifter motor Offsets the paper.
POD1 Fusing after detection After fusing, paper exit from fusing section is detected.
POD2 Paper exit detection Detects the exit paper.
POFM_F Paper exit cooling fan motor (F side) Cools the fusing unit.
POFM_R Paper exit cooling fan motor (R side) Cools the fusing unit.
POM Paper exit drive motor Drives the paper exit roller.
TFD2 Paper exit full detection Detects face-down paper exit tray full.
