Sharp MX-2300 G

MX-2300/2700 N/G MAINTENANCE 9 – 12
I. Transport section/Paper exit reverse section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the Parts Guide.
Block/Item No.
(Only the replacement parts are
described.)
1 PS follower roller Mechanical
parts
✕ {{{{{{{{{ { { {
2 Transport rollers { {{{{{{{{{ { { {
3 Discharge brush ✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
4 Paper exit filter
5 Gears ✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕When checking, apply to the
necessary positions (specified
positions).
1
1
1
3
3
3
2
2
2
2
4
4
: Dec. 15 2005
1
