Sharp MX-2300 G

MX-2300/2700 N/G FUSING SECTION N – 7
4. Maintenance
A. Fusing section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shif the position.
No. Parts name
Monochrome
supply,
mechanical
parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the
Parts Guide.
Block/Item No. (Only
the replacement parts
are described.)
1 Upper heat roller Mechanism
parts
✕ ✕▲✕▲✕▲✕▲✕ ▲ ✕ ▲(P/G No.: [32]-32)
2 Lower heat roller ✕ ✕▲✕▲✕▲✕▲✕ ▲ ✕ ▲(P/G No.: [33]-15)
3 Upper heat roller
gear
✕ ✕▲✕▲✕▲✕▲✕ ▲ ✕ ▲(P/G No.: [32]-30)
4 Upper roller bearing ✕ ✕▲✕▲✕▲✕▲✕ ▲ ✕ ▲(P/G No.: [32]-31)
5 Lower heat roller
bearing
✕ ✕▲✕▲✕▲✕▲✕ ▲ ✕ ▲(P/G No.: [33]-14)
6 Upper separation
pawl
✕ ✕▲✕▲✕▲✕▲✕ ▲ ✕ ▲(P/G No.: [32]-11)
7 Upper thermistor ✕ ✕▲✕▲✕▲✕▲✕ ▲ ✕ ▲(P/G No.: [32]-18)
8 Lower thermistor ✕ ✕▲✕▲✕▲✕▲✕ ▲ ✕ ▲(P/G No.: [33]-20)
9 Non-contact
thermistor
✕ ✕✕▲✕✕▲✕✕▲ ✕ ✕ ▲
10 Gears ✕ ✩✩✩✩✩✩✩✩✩ ✩ ✩ ✩Specified position
11 Paper g uide { {{{{{{{{{ { { {
12 Fusing unit ✕ ✕▲✕▲✕▲✕▲✕ ▲ ✕ ▲(P/G No.: [31]-901)
(P/G No.: [32]-901)
(P/G No.: [33]-901)
5
5
8
2
4
4
6
6
2
1
3
1
8
7
9
12
7
9
11
11
11
