MX-2300/2700 N/G DUPLEX SECTION G – 6
4. Maintenance
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shif the position.
No. Parts name
Monochrome
supply,
mechanical
parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to
the Parts Guide.
Block/Item No.
(Only the
replacement parts
are described.)
1 Transport rollers Mechanism parts { {{{{{{{{{ { { {
2 Discharge brush ✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
3Gears ✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕When checking,
apply to the
necessary positions.
(Specified positions)
2
2
1
