Sharp MX-2300 G

MX-2300/2700 N/G SCANNER SECTION C – 7
4. Maintenance
A. Optical Section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shif the position.
No. Parts name
Monochrome
supply,
mechanical parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to
the Parts Guide.
Block/Item No.
(Only the
replacement parts
are described.)
1 Mirror/lens/
reflector/CCD
Mechanism parts { {{{{{{{{{ { { {
2 Table glass/SPF
glass
{ {{{{{{{{{ { { {
3 Scanner lamp { {{{{{{{{{ { { {
4 Rails ✩ ✩✩✩✩✩✩✩✩✩ ✩ ✩ ✩Specified position
5 Drive belt/drive
wire
✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
4
2
4
2
4
3
5
5
1
1
1
4
