Sharp MX-2300 G

MX-2300/2700 N/G MAINTENANCE 9 – 9
F. Optical section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the Parts Guide.
Block/Item No.
(Only the replacement parts are
described.)
1 Mirror/Lens/
Reflector/CCD
Mechanical
parts
{ {{{{{{{{{ { { {
2 Table glass/
SPF glass
{ {{{{{{{{{ { { {
3 Scanner lamp { {{{{{{{{{ { { {
4 Rails ✩ ✩✩✩✩✩✩✩✩✩ ✩ ✩ ✩Specified positions
5Drive belt/
Drive wire
✕ ✕✕✕✕✕✕✕✕✕ ✕ ✕ ✕
4
2
4
2
4
3
5
5
1
1
1
4
