MX-2300/2700 N/G SIMULATION 7 – 17
8-6
Purpose : Operation test/Check/Adjustment
Function (Purpose) : Used to check and adjust the operation of
the transfer voltage and the control circuit.
Section : Process (Photoconductor/Developing/
Transfer/Cleaning)/Transfer
Item :Setting
Operation/Procedure
1) Select a target item to be adjusted with [↑] [↓] buttons.
2) Enter the adjustment value with 10-key.
3) Press [EXECUTE] button.
The set value is saved and the voltage corresponding to the
set value is outputted for 30 sec.
When [EXECUTE] button is pressed, the output is terminated.
Button Item Display Content
Setting
range
Default
value
MIDDLE A MIDDLE
SPEED
GB_K
K charging/grid
bias set value at
middle speed
230 to 850 615
B MIDDLE
SPEED
GB_C
C charging/grid
bias set value at
middle speed
230 to 850 615
C MIDDLE
SPEED
GB_M
M charging/grid
bias set value at
middle speed
230 to 850 615
D MIDDLE
SPEED
GB_Y
Y charging/grid
bias set value at
middle speed
230 to 850 615
LOW A LOW
SPEED
GB_K
K charging/grid
bias set value at
low speed
230 to 850 605
BLOW
SPEED
GB_C
C charging/grid
bias set value at
low speed
230 to 850 605
CLOW
SPEED
GB_M
M charging/grid
bias set value at
low speed
230 to 850 605
DLOW
SPEED
GB_Y
Y charging/grid
bias set value at
low speed
230 to 850 605
0
:
A㧦615
B㧦615
C㧦615
㧧 MIDDLE SPEED GB_K
㧧 MIDDLE SPEED GB_C
㧧 MIDDLE SPEED GB_M
SIMULATION
NO.08
㧙
02
MHV/GRID SETTING AND OUTPUT
615
㨇230㨪 850㨉
OK
TEST
CLOSE
EXECUTE
D㧦615
㧧 MIDDLE SPEED GB_Y
LOWMIDDLE
Item Display Content
Setting
range
Default
value
Actual output
setting range
Default
value
Actual
output value
A TC1 LOW SPEED CL K Primary transfer
bias reference
value
COLOR K Low speed 0 to 255 232 –500V to 5000V 4500V
B TC1 MIDDLE SPEED CL K Middle speed 0 to 255 232 –500V to 5000V 4500V
C TC1 LOW SPEED CL CMY CMY Low speed 0 to 255 139 –500V to 5000V 2500V
D TC1 MIDDLE SPEED CL CMY Middle speed 0 to 255 139 –500V to 5000V 2500V
E TC1 LOW SPEED BW K BLACK K Low speed 0 to 255 232 –500V to 5000V 4500V
F TC1 MIDDLE SPEED BW K Middle speed 0 to 255 232 –500V to 5000V 4500V
G TC2 PLAIN CL SPX Secondary transfer
bias reference
value
COLOR Normal
paper
Front surface 51 to 255 100 2µA to 45µA12.5µA
H TC2 PLAIN CL DPX Back surface 51 to 255 100 2µA to 45µA12.5µA
I TC2 PLAIN BW SPX BLACK Front surface 51 to 255 90 2µA to 45µA10µA
J TC2 PLAIN BW DPX Back surface 51 to 255 90 2µA to 45µA10µA
K TC2 HEAVY1 CL SPX COLOR Heavy paper 51 to 255 69 2µA to 45µA6µA
L TC2 HEAVY1 BW SPX BLACK 51 to 255 69 2µA to 45µA6µA
M TC2 OHP CL COLOR OHP 51 to 255 60 2µA to 45µA4µA
N TC2 OHP BW BLACK 51 to 255 60 2µA to 45µA4µA
O TC2 ENVELOPE CL COLOR Envelope 51 to 255 184 2µA to 45µA30µA
P TC2 ENVELOPE BW BLACK 51 to 255 184 2µA to 45µA30µA
Q TC2 CLEANING Cleaning process 51 to 255 79 2µA to 45µA8µA
R TC2 CLEAN LOW SPD Secondary transfer
cleaning bias
reference value
Low speed print 51 to 255 72 –50V to –1500 –200V
S TC2 CLEAN MIDDLE SPD Middle speed print 51 to 255 72 –50V to –1500V –200V
T TC2 CLEAN CLEANING Cleaning 51 to 255 156 –50V to –1500V –800V
CLOSE
A:
A : 232
B : 232
C: 139
TC1 LOW SPEE D
CL
K
TC1 MIDDLE SPEED
CL
K
TC1 LOW SPEE D
CL
CMY
SIMULATI ON
NO.08-06
THV SETTING AND OUTPUT
232
[ 0~255]
OK
TEST
EXECUTE
0
D : 139
TC1 MIDDLE SPEED CL
CMY
CLOSE
To Next Page
