Sharp MX-2300 G

MX-2300/2700 N/G SIMULATION 7 – 16
7-8
Purpose : Operation display
Function (Purpose) : Used to display the warm-up time.
Section :Fusing
Item : Operation
Operation/Procedure
Press [EXECUTE] button.
Counting of the warm-up time is started.
* Interruption of counting by pressing [EXECUTE] button is inhib-
ited.
7-9
Purpose : Operation test/check
Function (Purpose) : Used to check printing in the color mode.
Section :—
Item : Operation
Operation/Procedure
1) Select a print color with buttons on the touch panel.
2) Press [EXECUTE] button.
Printing is started in the selected color.
* If no color is specified, printing is made in all colors.
8
8-1
Purpose : Operation test/Check/Adjustment
Function (Purpose) : Used to check and adjust the operations of
the developing voltage of each color and
the control circuit.
Section : Process (Photoconductor/Developing/
Transfer/Cleaning)
Item : Operation
Operation/Procedure
1) Select a speed with [MIDDLE] and [LOW] buttons on the touch
panel.
2) Select a target item to be adjusted with [↑] [↓] buttons.
3) Enter the adjustment value with 10-key.
4) Press [EXECUTE] button.
The set value is saved and the voltage corresponding to the
set value is outputted for 30 sec.
* The adjustment values of [MIDDLE] and [LOW] are related
together.
* When [EXECUTE] button is pressed, the output is terminated.
8-2
Purpose : Operation test/Check/Adjustment
Function (Purpose) : Used to check and adjust the operation of
the main charger grid voltage in each
printer mode and the control circuit.
Section : Process (Photoconductor/Developing/
Transfer/Cleaning)
Item : Operation
Operation/Procedure
1) Select a speed with [MIDDLE] and [LOW] buttons on the touch
panel.
2) Select a target item to be adjusted with [↑] [↓] buttons.
3) Enter the adjustment value with 10-key.
4) Press [EXECUTE] button.
The set value is saved and the voltage corresponding to the
set value is outputted for 30 sec.
* The adjustment values of [MIDDLE] and [LOW] are related
together.
* When [EXECUTE] button is pressed, the output is terminated.
K Setup/cancel of black
C Setup/cancel of cyan
M Setup/cancel of magenta
Y Setup/cancel of yellow
0
SIMULATION  NO.07  08
TEST
WARM UP TIME DISPLAY SETTING
CLOSE
EXECUTE
0SECONDS
CLOSE
0
 K
SIMULATION  NO.07  09
TEST
PRINTING COLOR SELECT(COLOR MODE)
C
M
Y
1/1
EXECUTE
Button Item Display Content
Setting
range
Default
value
MIDDLE A MIDDLE
SPEED DVB_K
K developing
bias set value
at middle speed
0 to 700 450
B MIDDLE
SPEED DVB_C
C developing
bias set value
at middle speed
0 to 700 450
C MIDDLE
SPEED
DVB_M
M developing
bias set value
at middle speed
0 to 700 450
D MIDDLE
SPEED DVB_Y
Y developing
bias set value
at middle speed
0 to 700 450
LOW A LOW SPEED
DVB_K
K developing
bias set value
at low speed
0 to 700 430
B LOW SPEED
DVB_C
C developing
bias set value
at low speed
0 to 700 430
C LOW SPEED
DVB_M
M developing
bias set value
at low speed
0 to 700 430
D LOW SPEED
DVB_Y
Y developing
bias set value
at low speed
0 to 700 430
㩷
0
A
:
A㧦450
B㧦450
C㧦450
㧧 MIDDLE SPEED DVB_K
㧧 MIDDLE SPEED DVB_C
㧧 MIDDLE SPEED DVB_M
SIMULATION  NO.08 㧙 01
DV SETTING AND OUTPUT
450
㨇0㨪 700㨉
OK
TEST
CLOSE
EXECUTE
D㧦450
㧧 MIDDLE SPEED DVB_Y
LOWMIDDLE
