Sharp MX-2300 G

MX-2300/2700 N/G SIMULATION 7 – 15
6-2
Purpose : Operation test/check
Function (Purpose) : Used to check the operations of each fan
motor and its control circuit.
Section : Other
Item : Operation
Operation/Procedure
1) Select the item to be checked with the buttons on the touch
panel.
2) Press [EXECUTE] button.
The selected load operation is performed.
When [EXECUTE] button is pressed, the operation is termi-
nated.
6-3
Purpose : Operation test/check
Function (Purpose) : Used to check the operations of the primary
transfer unit and the related circuit.
Section : Process (Transfer)
Item : Operation
Operation/Procedure
1) Press [EXECUTE] button.
2) The load operation is started. (Separation operation: BLACK
→ COLOR → FREE Stops at each position for 5 sec.) During
the operation, the current position is displayed.
7
7-1
Purpose :Setting
Function (Purpose) : Used to set the operating conditions of
aging.
Section : Other
Item : Operation
Operation/Procedure
1) Select the target to be set with buttons on the touch panel.
2) Press [EXECUTE] button.
The machine is rebooted in the aging mode.
The contents set with this simulation are retained until the
power is turned OFF.
7-6
Purpose :Setting
Function (Purpose) : Used to set the intermittent aging cycle.
Section : Other
Item : Operation
Operation/Procedure
1) Enter the intermittent aging cycle (unit: sec) with 10-key.
2) Press [OK] button.
The time entered in procedure 1) is set.
POFM Paper exit cooling fan motor (* POFM_U, POFM_F, and
POFM_R are driven at the same time.)
OZFM Ozone fan motor
PSFM Power cooling fan motor
BLACK Black mode position Black mode position
→ COLOR mode position
→ Drum separation position
→ Shift to the black mode
position is repeated.
COLOR COLOR mode position
FREE Drum separation position
㩷
㩷
㩷
㩷
㩷
㩷
㩷
㩷
SIMULATION  NO.06  02
TEST
FAN L OAD S ET UP
 POFM
OZFM
PSFM
1/1
 EXECUTE
0
CLOSE
0
SIMULATION  NO.06  03
TEST
TRANSFER LOAD CHECK
EXECUTE
POSITION

:



1/1
CLOSE
AGING Aging operation setup
INTERVAL Intermittent setup
MISFEED DISABLE JAM detection enable/disable setup
FUSING DISABLE Fusing operation enable/disable setup
WARMUP DISABLE Warm-up disable setup
DV CHECK DISABLE DV unit detection enable/disable setup
SHADING DISABLE Shading disable setup
CCD GAIN FREE CCD gain adjustment free setup
Item Item Set range Default value
A CYCLE TIME(SEC) 1 to 900 3
SIMULATION  NO.07  01
TEST
AGING TEST SETTING
 AGING
INTERVAL
MISFEED DISABLE
FUSING DISABLE
WARMUP DISABLE
DV CHECK DISABLE
1/1
EXECUTE
0
SHADING DISABLE
CCD GAIN FREE
CLOSE
0
A
:
A㧦 3
㧧 CYCLE TIME(SEC)


SIMULATION  NO.07-06
INTERVAL AGING CYCLE TIME SETUP
 3
㨇 1㨪 900 㨉
OK
TEST
CLOSE
