MX-2300/2700 N/G SPECIFICATIONS 2 – 2
(10) Auto Color Selection
(11) Power source
(12) Power consumption
*1: Heater is OFF when power source ON.
(13) Noise
(14) Dimensions
(15) Weight
(16) Dimensions occupied by Machine (with Multi
Manual/Exit tray extended)
B. Paper feed unit/Transport/Paper exit secton
(1) Machine paper feed tray
(2) Paper feed tray 1/tray 2
(3) Manual feed tray (Bypass tray)
Copy Print Scan
Read The decision -color
or monochrome- is
decided when the
document is
scanned.
The scanning
speed for color is
always adopted.
N/A The decision -color
or monochrome- is
decided when the
document is
scanned.
The scanning
speed for color is
always adopted.
Output For the output of a black-white original,
the decision to switch from color mode
to black-white mode is made when the
drum running distance shortens.
First copy (print):
If a fixed number of black-white pages
are contained in a series, switch from
color mode to black-white mode, starting
with the first page of the batch. If the
original starts with a black-white page,
the output will start in the black-white
mode.
From the second copy (print) on:
The condition is completely understood.
If there are a fixed number of black-
white pages in a series, switch to the
black-white mode, starting with the first
page in the series.
N/A
Count Black-white count for the pages recognized as black-white.
Color count for the pages recognized as colored.
For N-UP, a page will be counted as a color page if there is at
least one colored page inserted upon N-UP.
100V type 200V type
Voltage / Current 100 – 127V 12A 220 – 240V 8A
Frequency 50/60Hz
Power source
code
Fixed type (direct) Inlet type
Power switch 2 switches (Primary switch: in the front cover;
Seconday switch: the operation panel)
100V type 200V type
Maximum rated power
consumption
1.44kW 1.84kW
In action B/W : 63dB or less
Color : 63dB or less
Standby B/W : 55dB or less
MX-2300G/MX-2700G MX-2300N/MX-2700N
Outer dimensions
(W x D x H)
(with Multi
Manual)
620 x 670 x 795mm
(24 13/32 x 26 3/8 x
31 inch)
620 x 670 x 950mm
(24 13/32 x 26 3/8 x
37 26/64 inch)
Footprint (W x D) 590 x 670mm
(23 15/64 x 26 3/8 inch)
590 x 670mm
(23 15/64 x 26 3/8 inch)
MX-2300G/MX-2700G MX-2300N/MX-2700N
Main unit Approx. 102kg (225lbs) Approx. 112kg (247lbs)
Main unit +
Developer +
Toner cartridge
Approx. 106kg (234lbs) Approx. 116kg (256lbs)
MX-2300G/MX-2700G MX-2300N/MX-2700N
W1050 x D670mm (W41-22/64 x D26-3/8 inch)
Form Standard: Double feeder tray + multi manual
Maximum: Fourfold feeder tray + multi manual +
large capacity feeder cassette
Feeding method Feeding from the upper section with front loading
Heater (Engine part) Service parts
Feeding method Feeding from the upper section with front loading
Heater (Engine part) Service parts
Paper size A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR
11 x 17, 8.5 x 14, 8.5 x 13, 8.5 x 11,
8.5 x 11R, 7.25 x 10.5R, 5.5 x 8.5R
Changing of paper
size
Guide adjustment by users and size setting
through key input
Paper type setting Yes
Default paper size
setting
(Tray 1)
Abroad-AB : A4
Abroad-inches : 8.5 x 11
(Tray 2)
Abroad-AB : A3
Abroad-inches : 11 x 17
Feedable paper
type/weight
Plain paper: 60-105g/m
2
(16-28 lbs)
Paper capacity Standard paper: 500 sheets (80g/m
2
, 21lbs)
Paper Type Plain paper, pre-printed paper (not including
backing paper), recycled paper, letter head, pre-
punched paper, colored paper
* Users can set up all of these paper types.
Paper size detection
(Size setting through
key input)
A3, B4, A4, A4R, B5, B5R, A5R, 8.5 x 13
11 x 17, 8.5 x 14, 8.5 x 11, 8.5 x 11R, 5.5 x 8.5R,
7.25 x 10.5R, 8K, 16K, 16KR
Detection of
Remaining Paper
Level detection (4 levels: 100%, 67%, 33%, and
none)
Paper Size A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR
12 x 18, 11 x 17, 8.5 x 14, 8.5 x 13, 8.5 x 11, 8.5 x
11R, 7.25 x 10.5R, 5.5 x 8.5R
Envelope (Monarch / Com-10 / DL / C5 / Rectangle 3 /
Western 2 / Western 4)
Extra Size (Tab paper is limited to A4; tab width
12mm-20mm / 8.5 x 11; tab width 6.1-17mm)
Changing of
paper size
Guide adjustment by users
Paper type setting Yes
Feedable paper
type/weight
Thin paper: 55 – 59g/m
2
(15 – 16 lbs)
Plain paper: 60 – 105g/m
2
(16 – 28 lbs)
Heavy Paper: 106 – 209g/m
2
(28+ – 56 lbs)
Envelope: 75 – 90g/m
2
(20 – 24 lbs)
OHP
Label paper
Tab paper
Gloss Paper
Paper capacity Standard paper: 100 sheets
Envelope: 20 sheets
OHP: 20 sheets
Heavy paper: 40 sheets
Tab paper: 20 sheets
Gloss paper: 20 sheets
Other special paper: 1 sheet
Paper Type Plain paper, pre-printed paper (Excluding back print
paper), recycled paper, letter head, pre-punched
paper, colored paper, heavy paper, thin paper, label
paper, OHP, tab paper, envelope.
* Users can set up all of these paper types.
