MX-2300/2700 N/G SPECIFICATIONS 2 – 11
(5) Print channel
(6) Command Compatibility
(7) Environmental settings
(8) Print functions
Support print
channel
• USB2.0 (high speed)
• PSERVER/RPRINT for netware environment
•LPR
•IPP
• PAP: EtherTalk (AppleTalk)
•FTP
•NetBEUI
• Raw Port (Port9100)
• HTTP (Web Submit Print)
• POP3 (E-Mail To Print)
USB USB 1.1: Windows 98/Me/2000/Server 2003/XP only
USB 2.0 (High speed): Windows 2000/XP only
PSERVER/
RPRINT for
NetWare
environment
Print channel in PSERVER/PRINT mode to be used
in netware environment
LPR UNIX LPR/LPD command-compatible print channel
IPP Print channel in compliance with IPP1.0
PAP:
EtherTalk
(AppleTalk)
Print channel to be used for Machintosh environment
FTP Equipped with the function to print data received via
built-in FTP server
NetBEUI Microsoft NetBEUI compatible print channel
Port9100 9100 TCP port (Raw Port) supported
PCL5c
compatibility
PCL5c must be compatible with HP Color Laser Jet
4600.
PCL XL
compatibility
PCL XL must be compatible with HP Color Laser Jet
4600.
PostScript
compatibility
Must be compatible with Adobe PS3.
Setting item Overview
Initial setting Basic settings for printer use such as number of
copies or printing direction.
PCL seting Setting of PCL symbols and fonts
PS setting Whether or not printing is allowed upon PS error is to
be set up.
Function Content
PCL6/5c
(G model:
option)
PS (Option)
SPLC-c
(G model)
Multiple Pamphlet Binds multiple pamphlet outputs into a single booklet. Yes Yes No
Bar code font JetCAPS BarDIMM emulation Yes No No
Network tandem print Two units connected via network can be used simultaneously for a printout. Yes Yes (Windows
only)
No
Encryption PDF/PDF/
TIFF/JPEG direct print
PDF/TIFF/JPEG file can be printed without printer driver.
1) Printing of e-mail attachment file
2) Printing from FTP server
3) Printing from setup file on Web page
4) USB memory
Yes ( N o f o r
encrypted
PDF/PDF)
Yes No
E-Mail To Print Direct printing of an attached file upon receipt of the e-mail. Yes Yes No
Pull print from front panel Browsing of FTP server from front panel and pull-printing of a specified file (direct
printing).
Yes Yes No
Print by file setup on Web
page [Web Submit Print]
Setting and direct printing of a file on network through Web page. Yes Yes No
Continuous print function The function executes multiple print jobs continuously as if they are one single job
even if the unit receives an end of job command, in order to support print from the
application assuming printout on continuous pages.
Yes Yes No
ROPM The function enables the printout of a multiple number of copies in one RIP
processing.
Yes Yes Yes
Multi-access RIP processing must be allowed during printing. Printing must also be allowed
during scanning.
Yes Yes Yes
Paper direction setting for
2-sided printing of
letterhead paper and pre-
punched paper.
Pages with front-back attribute such letterhead or punch paper are to be printed
correctly in front-back page order for 2-sided printing.
Yes Yes Yes
Enable selected paper
type in bypass tray
For setting of bypass tray, even if the setup values on the main unit side do not
match with those on the driver side, the printing will be executed in the setting of
the driver regardless of the setup values on the main unit side.
Yes Yes Yes
Setting environmental
control under terminal
server control
Print setting of each client is memorized under meta frame environment (auto print
create environment). (Setup for each log-in can be skipped.)
Yes Yes Yes
Driver delivery function PAU4.0 allows the administrator to deliver a driver to clients. Yes Yes Yes
Form overlay The function downloads a form to the main unit beforehand, sends the contained
data only, and inserts the data into the form in the main unit for printout.
Yes
(5c only)
No No
Planet Press Object Lune Corporation's Planet Press (Software to execute the mapping of forms
(DL beforehand) and variable data in the printer interior)
Yes Yes No
Improvement of
downloading method of
font form
This expands the function to prevent the deletion and overwriting of the editing
functional enhancement font/form on Web page. A unified UI for the lineup is
necessary.
Currently, registration is done by Web page and deleted by PJL. This function is
supported by HDD.
Yes
(5c only)
Yes No
Management of password
by hidden Web page
The purpose is to prevent the access even if the hidden Web page address
becomes known.
Yes Yes Yes
Expansion font list In self-print of a font list, ESC command information is needed for BITMAP font. Yes
(5c only)
No No
