MX-2300/2700 N/G SIMULATION 7 – 87
46-47
Purpose : Setting
Function (Purpose) : Used to set the JPEG compression rate in
Copy/Scanner (PUSH SCAN).
Section :—
Item : Setting
Operation/Procedure
1) Select the set item with [↑] and [↓] buttons.
The highlighted set value is switched and the value is dis-
played in the setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
2) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
3) When [OK], [↑], [↓] button, [COLOR], or [BLACK] key is
pressed, the currently entered data are saved to EEPROM and
RAM.
<Set range and default value of each setup>
48
48-1
Purpose : Adjustment
Function (Purpose) : Used to execute the magnification adjust-
ment in the scan system (for RSPF).
Section : RSPF/Scanner
Item : Image quality (Size/magnification ratio)
Operation/Procedure
1) Select the set item with [↑] and [↓] buttons.
The highlighted set value is switched and the value is dis-
played in the setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
2) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
3) When [OK], [↑], [↓] button, [COLOR], or [BLACK] key is
pressed, the current entered value is saved to EEPROM and
RAM.
* Copying can be performed also by pressing [COLOR]/
[BLACK] key.
* When [CLOSE] button is pressed, the display is shifted to
the copy basic screen of simulation.
0
A:
A㧦 50
㧧 AUTO
B㧦 50 㧧 EXPOSURE1
SIMULATI ON  NO.46-45
EXPOSURE ADJUSTMENT(FAX㧦600DPI)
50
㨇 1㨪 99㨉
OK
TEST
EXECUTE
CLOSE
C㧦 50 㧧 EXPOSURE2
D㧦 50 㧧 EXPOSURE3
Category Item Display Content Set range Default value
COPY (COLOR) A COPY (C) LOW Low compression (Color) 0 0 (LOW)
MIDDLE Middle compression (Color) 1
HIGH High compression (Color) 2
COPY (GRAY) B COPY (G) LOW Low compression (Gray) 0 0 (LOW)
MIDDLE Middle compression (Gray) 1
HIGH High compression (Gray) 2
PUSH SCAN (COLOR) C SCAN (C) MIDDLE1 Middle compression mode 1, for compression, Q table (for
brightness, color difference)
0 0 (MIDDLE1)
Middle compression mode 1, for decompression, Q table (for
brightness, color difference)
MIDDLE2 Middle compression mode 2, for compression, Q table (for
brightness, color difference)
1
Middle compression mode 2, for decompression, Q table (for
brightness, color difference)
MIDDLE3 Middle compression mode 3, for compression, Q table 2
Middle compression mode 3, for decompression, Q table
PUSH SCAN (GRAY) D SCAN (G) MIDDLE1 Middle compression mode 1, for compression, Q table 0 0 (MIDDLE1)
Middle compression mode 1, for decompression, Q table
MIDDLE2 Middle compression mode 2, for compression, Q table 1
Middle compression mode 2, for decompression, Q table
MIDDLE3 Middle compression mode 3, for compression, Q table 2
Middle compression mode 3, for decompression, Q table
A
:
A㧦 0
B㧦 0
C㧦 0
C㧦 0
㧧 COPY(C)㧦LOW
㧧 COPY(G)㧦LOW
㧧 SCAN(C)㧦MIDDLE㧝
㧧 SCAN(G)㧦MIDDLE㧝
SIMULATION  NO.46  47
COPY࡮SCAN COMPRESS RATE ADJUSTMENT
0
㨇 0㨪 2 㨉
OK
TEST
0
CLOSE
