MX-2300/2700 N/G SIMULATION 7 – 107
If there is no item over [↓], the display grays out and the
operation is invalid.
2) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
3) When [OK], [↑], [↓] button, [COLOR], or [BLACK] key is
pressed, the current entered value is saved to EEPROM and
RAM.
* When [CLOSE] button is pressed, the display shifts to the
copy basic screen of simulation.
<Set range and default value of each set value>
<Expression of (Large size) and (Small size)>
(Small size): The paper length in the transport direction is LT
(216mm) or less.
(Large size): The paper length in the transport direction is longer
than LT (216mm).
<Adjustment value>
When the adjustment value is increased, the deflection quantity is
increased. When the adjustment value is decreased, the deflection
quantity is decreased. (When the adjustment value is changed by
1, the stop timing is changed by 0.1mm.)
Item Button Display item
Description of item (Mode, document, paper feed
speed)
Transport direction
Set
range
Default
value
A SIDE1 NORMAL_PLAIN_HIGH RSPF front surface document, deflection quantity
adjustment value (normal, plain paper, HIGH)
– 1 to 99 50
B NORMAL_PLAIN_LOW RSPF front surface document, deflection quantity
adjustment value (normal, plain paper, LOW)
– 1 to 99 50
C NORMAL_ THIN _HIGH RSPF front surface document, deflection quantity
adjustment value (normal, thin paper, HIGH)
– 1 to 99 50
D NORMAL__THIN LOW RSPF front surface document, deflection quantity
adjustment value (normal, thin paper, LOW)
– 1 to 99 50
E RANDOM_PLAIN_LOW RSPF front surface document, deflection quantity
adjustment value (random, plain paper, LOW)
– 1 to 99 50
F RANDOM_ THIN _LOW RSPF front surface document, deflection quantity
adjustment value (random, thin paper, LOW)
– 1 to 99 50
A SIDE2 NORMAL_PLAIN_HIGH_1 RSPF back surface document, deflection quantity
adjustment value 1(normal, plain paper, HIGH)
– 1 to 99 50
B NORMAL_PLAIN_LOW_1 RSPF back surface document, deflection quantity
adjustment value 1(normal, plain paper, LOW)
– 1 to 99 50
C NORMAL_PLAIN_HIGH_2 RSPF back surface document, deflection quantity
adjustment value 2(normal, plain paper, HIGH)
– 1 to 99 50
D NORMAL_PLAIN_LOW_2 RSPF back surface document, deflection quantity
adjustment value 2(normal, plain paper, LOW)
– 1 to 99 50
A ENGIN TRAY1(S) Main unit cassette 1 (upper stage), deflection
adjustment value (small size)
LT size or less 1 to 99 40
B TRAY1(L) Main unit cassette 1 (upper stage), deflection
adjustment value (large size)
Longer size than the above 1 to 99 40
C TRAY2(S) Main unit cassette 1 (upper stage), deflection
adjustment value (small size)
LT size or less 1 to 99 40
D TRAY2(L) Main unit cassette 1 (upper stage), deflection
adjustment value (large size)
Longer size than the above 1 to 99 40
E MANUAL PLAIN PAPER (S) Manual tray, deflection adjustment value (plain paper,
small size)
LT size or less 1 to 99 40
F MANUAL PLAIN PAPER (L) Manual tray, deflection adjustment value (plain paper,
large size)
Longer size than the above 1 to 99 40
G MANUAL HEAVY PAPER1 (S) Manual feed tray, deflection adjustment value (Heavy
paper, small size)
LT size or less 1 to 99 25
H MANUAL HEAVY PAPER1 (L) Manual feed tray, deflection adjustment value (Heavy
paper, large size)
Longer size than the above 1 to 99 25
I MANUAL OHP1 Manual feed tray, deflection adjustment value (OHP) – 1 to 99 40
J MANUAL ENV Manual feed tray, deflection adjustment value
(Envelope)
– 1 to 99 40
K ADU PLAIN PAPER (S) ADU, deflection adjustment value (Plain paper, small
size)
LT size or less 1 to 99 40
L ADU PLAIN PAPER (L) ADU, deflection adjustment value (Plain paper, large
size)
Longer size than the above 1 to 99 40
M ADU HEAVY PAPER1 (S) ADU, deflection adjustment value (Heavy paper, small
size)
LT size or less 1 to 99 25
N ENGIN ADU HEAVY PAPER1 (L) ADU, deflection adjustment value (Heavy paper, large
size)
Longer size than the above 1 to 99 25
O DESK(S) DESK, deflection adjustment value (Plain paper, small
size)
LT size or less 1 to 99 40
P DESK(L) DESK, deflection adjustment value (Plain paper, large
size)
Longer size than the above 1 to 99 40
Q A4LCC A4LCC, Deflection adjustment value 1 to 99 40
:
A㧦 50
B㧦 50
C㧦 50
D㧦 50
㧧 NORMAL_PLAIN_HIGH
㧧 NORMAL_PLAIN_LOW
㧧 NORMAL
HIGH
㧧 NORMAL_THIN_LOW
SIMULATI ON
NO.51
㧙
02
REGIST ROLLER ADJUSTMENT
50
㨇
1㨪 99 㨉
OK
TEST
CLOSE
SIDE1 SIDE2 ENGIN
