MX-2300/2700 N/G TRAY PAPER FEED SECTION E – 2
Signal name Name Function/Operation
CLUD1 Tray 1 upper limit detection (Lift HP detection) Tray 1 upper limit detection
CLUD2 Tray 2 upper limit detection (Lift HP detection) Tray 2 upper limit detection
CLUM1 Paper tray lift-up motor (Paper feed tray 1) Drives the paper tray lift plate.
CLUM2 Paper tray lift-up motor (Paper feed tray 2) Drives the paper tray lift plate.
CPED 1 Tray 1 paper empty detection Tray 1 paper empty detection
CPED 2 Tray 2 paper empty detection Tray 2 paper empty detection
CPFC Tray vertical transport clutch
CPFD1 Tray 1 transport detection (Paper entry detection) Tray 1 paper pass detection
CPFD2 Tray 2 transport detection (Paper entry detection) Tray2 paper pass detection
CPFM Paper feed motor Paper feed section drive
CPUC1 Paper feed clutch (Paper feed tray 1) Controls the paper feed tray section roller ON/OFF.
CPUC2 Paper feed clutch (Paper feed tray 2) Controls the paper feed tray section roller ON/OFF.
CSPD1 Tray 1 paper remaining quantity detection Tray 1 paper remaining quantity detection
CSPD2 Tray 2 paper remaining quantity detection Tray 2 paper remaining quantity detection
CSS1 Tray 1 presence detection Detects the presence of the tray 1
CSS2 Tray 2 presence detection Detects the presence of the tray 2
DSW_C Tray 1, 2 transfer cover open/close detection Detects opening of the tray 1, 2 transport cover.
No. Name Function/Operation
1 Paper feed roller (No.1 paper feed tray) Feeds paper to the paper transport section.
2 Paper pickup roller (No. 1 paper feed tray) Feeds paper to the paper feed roller.
3 Separation roller (No. 1 paper feed tray) Separates paper to prevent Double Feed.
4 Torque limiter A certain level of resistance force is supplied to the rotation of the separation
roller to prevent double feed.
5 Paper feed roller (No. 1 paper feed tray) Feeds paper to the paper transport section.
6 Paper pickup roller (No. 2 paper feed tray) Feeds paper to the paper feed roller.
7 Separation roller (No. 2 paper feed tray) Separates paper to prevent Double Feed.
8 Transport roller 4 (Drive) Transports the paper transported from the transport roller 1 and paper feed roller
(No. 2 paper feed tray) to the transport roller 7.
9 Transport roller 5 (Drive) Transports the paper fed from the paper tray 1 to the transport roller 7.
10 Transport roller 7 (Drive) Transports the paper fed from the paper feed tray 1, 2 or 3, 4 to the transport
roller 8.
11 Rotation plate Lifts up the paper to keep the paper feed position.
