MX-2300/2700 N/G LSU SECTION H – 5
b. Cleaning base
1) Remove the waste toner box.
2) Remove the LSU cleaning stick from the front cover.
3) Remove the cleaning base from the LSU cleaning rod.
4. Maintenance
A. LSU section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shif the position.
No. Parts name
Monochrome
supply,
mechanical
parts
When
calling
100
K
200
K
300
K
400
K
500
K
600
K
700
K
800
K
900
K
1000
K
1100
K
1200
K
Remark/Refer to the
Parts Guide. Block/
Item No. (Only the
replacement parts are
described.)
1 Dust-proof glass Mechanism
parts
{ {{{{{{{{{ { { {
2 Cleaning base ✕ ▲▲▲▲▲▲▲▲▲ ▲ ▲ ▲(P/G No.: [2]-35)
1
2
