Sharp MX-2300 G

MX-2300/2700 N/G ADJUSTMENTS 6 – 16
MAIN, SUB: The entered value after adjustment is displayed.
( ): Difference from the previous value.
Example: This time 105, previous time 103: 105 (+2)
* In case of an error, "ERROR" is displayed with the details.
To check the auto adjustment result, use the manual image
registration adjustment mode below.
* Image registration adjustment (Main scanning direction) (Manual
adjustment) (SIM50-20)
* Image registration adjustment (Sub scanning direction) (Manual
adjustment) (SIM50-21)
10-B Image registration adjustment (Main scan-
ning direction) (Manual adjustment)
1) Enter SIM50-20 mode.
2) Select the paper feed tray with A3 (11 x 17) paper in it by
changing the value of set item H.
3) Press [EXECUTE] key.
The image registration adjustment pattern in the main scan-
ning direction is printed.
A: Rough adjustment pattern
B: Fine adjustment pattern
C: Adjustment range (0 ± 1)
REGIST MAIN
R
C Image registration
adjustment value (Main
scanning direction)
(Cyan) (R side)
1.0 – 199.0 100
M Image registration
adjustment value (Main
scanning direction)
(Magenta) (R side)
1.0 – 199.0 100
Y Image registration
adjustment value (Main
scanning direction)
(Yellow) (R side)
1.0 – 199.0 100
SUB C Image registration
adjustment value (Sub
scanning direction)
(Cyan)
1.0 – 199.0 100
M Image registration
adjustment value (Sub
scanning direction)
(Magenta)
1.0 – 199.0 100
Y Image registration
adjustment value (Sub
scanning direction)
(Yellow)
1.0 – 199.0 100
Display/Item Content
Adjustment
value range
Default
value
EXECUTE
0
A:ġ
Aȇxxx
Bȇxxx
Ȉ CYAN(FRONT)
Ȉ CYAN(REAR)
SIMULA TIONġ NO.50-20
REGISTRATIONġ ADJUSTMENT : FRONT-REAR DIRECTION
xxx
ġ 1 199
OK
TEST
EXECUTE
CLOSE
Cȇxxx Ȉ MAGENTA(FRONT)
Dȇxxx Ȉ MAGENTA(REAR)
0
A:ġ
Aȇxxx
Bȇxxx
Ȉ CYAN(FRONT)
Ȉ CYAN(REAR)
SIMULA TIONġ NO.50-20
REGISTRATIONġ ADJUSTMENT : FRONT-REAR DIRECTION
xxx
1 199ġ
OK
TEST
EXECUTE
CLOSE
Cȇxxx Ȉ MAGENTA(FRONT)
Dȇxxx Ȉ MAGENTA(REAR)
EXECUTE
10-key
End of print
㪝㩷㫊㫀㪻㪼㩷㫄㪸㫉㫂
A
㪩㩷㫊㫀㪻㪼㩷㫄㪸㫉㫂
A
A
A
A
A
C C
C C
C C
B B
