10
4 Exploded Views of Instrument
Some of the parts in the Parts Used List are kept in stock as maintenance parts. For the types of
maintenance parts, refer to the Maintenance Parts List. Also, note that part Nos. in the Parts Used List
may differ from the part Nos. for maintenance parts. When ordering maintenance parts, refer to the
Maintenance Parts List.
4.1 Main Unit
4.1.1 View of Main Unit
4.1.2 Used Units List
No.
P/N
Part Name
20A
No.
P/N
Part Name
XS
20A
1
228-51451-91
Chassis Unit ASSY, XS
5
228-51454-91
Cover ASSY, RF-20A
1
1
1
228-51451-92
Chassis Unit ASSY
1
6
228-51146
Air Filter, Front
1
1
2
228-51540-91
Optical Unit ASSY, Super
7
228-51458-91
Filter Cover ASSY, Front
1
1
2
228-51540-92
Optical Unit ASSY, Low-Cost
1
8
228-51147
Air Filter, Side
1
1
3
228-51455-91
Front Panel ASSY, XS
9
228-51119
Filter Holder, Side
1
1
3
228-51455-92
Front Panel ASSY
1
10
228-45856-91
Cell Unit ASSY, XS
1
4
228-51461-91
PCB Unit ASSY, XS
10
228-45856-92
Cell Unit ASSY
1
4
228-51461-92
PCB Unit ASSY
1
20
228-50678-41
Cable, CPU-Temperature
Adjustment
1
