Shimadzu RF-20A - Automatic Adjustment Mode of Reflective Mirror (Motor) for Hg Lamps (V1.06)

37
6.12.2 Automatic Adjustment Mode of Reflective Mirror (Motor) for Hg Lamps (V1.06)
From the ROM version V1.06 "Automatic mode (LM AUTO ADJ)" and "Semi-auto mode (LM
ADJ)" were added to Hg lamp reflective mirror (motor) adjustment.
The operation procedure in the automatic mode is as follows.
- Procedure
(1) Change a cell for a PTFE block cell.
(2) Push [ENTER] key on the [LM AUTO ADJ] screen of FACTORY group.
(3) If operation is completed (after about 3 minutes), it will check that a result is
O.K.screen.(The number of pulses of a lamp mirror position [LM IMPUT] is automatic,
and is memorized)
(4) Remove a PTFE block cell and attach a flow cell. .. End
*2 When it is not 20AXS mode : "NOT 20AXS MODE" is displayed.
"PRODUCT TYPE" is set to 2 (20AXS).
LM AUTO ADJ
Enter to Start
LM AUTO ADJ xxx
Hg Lamp Heating
LM PLS－－－ xx
S 1256 /R 0
LM RESULT 29
S /R
LM SIGNAL LOW
S /R
[Enter]
About 2 minutes
Countdown (fabout 2
minutes)
Case of O.K.
Case of NG
Present position of a lamp
motor (26 - 35 pulses)
Sample
Energy value
*2
Returns to
former
screen by
CE key.
LM AUTO ADJ
LM Moving..
2) Initialization
Reference
Energy value
Aging of Hg lamp
1) Lamp mirror
automatic adjustment
start screen
4) Adjusting
5) Adjustment
result
LM AUTO ADJ
INITIALIZING..
SKIP of the aging can be
carried out by [ENTER] key.
* However, only when Hg
lamp is on 2 minutes or
more, please carry out.
