Shimadzu RF-20A - 13.2.2 Flow Cell;Piping Parts Maintenance Parts List

72
16
Motor ASSY EM
228-45948-91
Grating motor
17
Motor ASSY Hg Mirror
228-45744-95
Exclusively for XS
18
Belt, EX
228-45937
Grating drive timing belt
19
Belt, EM
670-11222
Grating drive timing belt
20
PMT Base ASSY, XS
228-51703-91
W/ PMT socket for XS
21
PMT Base ASSY
228-51703-92
W/ PMT socket for 20A
22
Photomultiplier R212
Photomultiplier R11568(New)
200-75033
228-59173
20A, 10AXL standard
Wavelength range: 200 to 650 nm
23
Photomultiplier R3788
200-75031
XS, 10AXL super standard
Wavelength range: 200 to 750 nm
24
Photomultiplier R928-08 (option)
200-75021
Wavelength range: 200 to 900 nm
13.2.2 Flow Cell/Piping Parts Maintenance Parts List
No.
Part Name
Part No.
XS
20A
Semimicro
Inert LC
1
Flow Cell ASSY, Temperature
Control
228-45856-91

2
Flow Cell ASSY
228-45856-92

3
Flow Cell ASSY for Semimicro LC,
Temperature Control
228-51950-91

4
For Flow Cell ASSY for Inert LC
228-51951-91

5
Flow Cell
228-48626



6
Flow Cell, SM
228-50502

7
Lens, Cell EX
228-48699-01



8
Lens, Cell EM
228-48700




9
Lens, EX Semimicro
228-50534-01

10
Mirror, Cell EX
228-52285-91



11
Mirror, EX Semimicro
228-52483-91

12
Mirror, Cell EM
228-52286-91




13
Joint ASSY, 20AXS (Inlet/Outlet)
228-54701-91

14
Joint ASSY, 20A (Inlet/Outlet)
228-54701-92

15
Joint ASSY, SM (Inlet/Outlet)
228-52187-91

16
Block, Bushing, Insert
228-51292

17
Tube, Insert 110 mm Long (Inlet)
228-52516-91

18
Tube, Insert 125 mm Long (Outlet)
228-52516-92

19
Fitting, F-126
228-52267-01

20
Block, PEEK, Cell
228-51177

