50
24
CELL TEMP
xx.x℃
SET xx℃
Monitor: Cell temperature
Monitor: Set temperature
25
LEAK SENSE
xxx
F
Monitor: Sample side of leak sensor
548 (evaluation unit)
26
LEAK ROOM xxx
F
Monitor: Reference side of leak sensor
310 (evaluation unit)
27
CLEAR ALL
ENTER TO
START
F
Initialization of parameters (factory default
values)
28
PMT TYPE x
Input 0 to 3
F
Sets the type of PMT. (Only changes the PMT
TYPE display during the system check. Other
displays are not affected.)
0= OTHER
1= RF-20A STD (R212)
2= RF-20AXS STD (R3788)
3= WIDE RANGE (R928-08), Option
Set this parameter
when switching the
photomultiplier to the
option.
29
PRODUCT TYPE
x
1: 20A 2: 20AXS
F
Set either 20A or 20AXS as the instrument.
30
AD SAMPLING x
0: 20 ms 1:
10 ms
F
Changes the data sampling interval.
31
AD PGA SET x
Input 0 to 6
F
Changes the gain of the A/D converter.
Do not change this
parameter.
32
AD SMP RATE x
Input 0.1 to 8
F
Changes the conversion time of the A/D
converter.
Do not change this
parameter.
33
EM PULSE
xxxxx
HP: 0 P: +-32767
F
EM-side grating motor pulse movement.
0: Home position after home position detection
0.7 nm movement per pulse (0.7 nm/pulse)
[Example]200: 0-order light, 970: green light,
1100: red light
34
EX PULSE
xxxxx
HP: 0 P: +-32767
F
EX-side grating motor pulse movement.
0: Home position after home position detection
0.7 nm movement per pulse (0.7 nm/pulse)
[Example] 200: 0-order light, 970: green light,
1100: red light
35
LM PULSE
xxxxx
HP: 0 P: +-32767
F
LM motor manual movement. Setting "0" moves
the motor to its home position. Enter a ± number
of pulses, and start movement by the [ENTER]
key.
36
LM AUTO ADJ
Enter to Start
F
It is the completeness automatic mode which is
automatic and adjusts the reflective mirror
(motor) for Hg lamps.
Usually, please use this mode.
.
37
LM ADJ x x
S 1256 /R 0
A push on a
number key
moves a mirror.
S: Sample side
energy
R: Reference
side energy
F
It is the semi auto mode which adjusts the
reflective mirror (motor) for Hg lamps by semi
auto.
Usually, although adjusted using the
completeness automatic mode, when you
change into the state where some troubles occur
and it cannot adjust in the completeness
automatic mode, please use this mode.
0: Initial position
1: -10 pulse movement
4: -1 pulse movement
3: +10 pulse movement
6: +1 pulse movement
