Figure 15: Position of the LEDs, the address switches and the preset pushbutton
1
Net
2
Mod
3
Link 1
4
Encoder
5
Link 2
6
Screw cover
The LEDs are multicolored. see "Error and status indications of the LEDs", page 106 for
the meaning of the signals.
The following control elements are located under the screw cover:
•
Address switch
•
Preset pushbutton
3
