6.1 Home
NOTE
All displayed values are updated about once a second.
6.1.1 Device
This page lists the basic data about the encoder.
In addition, an LED symbol indicates the following status:
Green Encoder is in Operational status (ready for operation, no
alarms, warnings or errors occurred).
Green Incorrect scaling parameters present.
Red The alarm flag is set.
Red The warning flag is set.
A detailed description of the alarms, warnings or errors that have occurred can be
found on the web server Diagnose page (see "Diagnostics", page 101).
6.1.2 Position
This page shows the following parameters from the position sensor object (see
table 24, page 29):
•
Current position value (attribute ID 0Ah)
•
Lower limit of the position (attribute ID 16h)
•
Upper limit of the position (attribute ID 17h)
The limit values can be changed via the “AuthorizedClient” user (see "Limits",
page 100).
6.1.3 Speed
This page shows the following parameters from the position sensor object (see
table 24, page 29):
•
Current speed (attribute ID 18h)
The unit of speed is defined by attributes 19h and 20h.
•
Lower speed limit (attribute ID 1Bh)
•
Upper speed limit (attribute ID 1Ch)
The limit values can be changed via the “AuthorizedClient” user (see "Limits",
page 100).
6.1.4 Temperature
This page shows the following parameters from the position sensor object (see
table 24, page 29):
•
Current temperature (attribute ID 64h)
The temperature is displayed with ± 5° accuracy.
•
Lower limit of the temperature (attribute ID 67h)
•
Upper limit of the temperature (attribute ID 68h)
The limit values can be changed via the “AuthorizedClient” user (see "Limits",
page 100).
6.1.5 Timer
This page shows the following parameters from the position sensor object (see
table 24, page 29):
