Operating instructions Chapter 11
Flexi Classic
8011509/YPP0/2015-10-26 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 111
Subject to change without notice
Technical specifications
Load
type
I[A] Switching frequency
Switching operations
per annum
B
10d
PFHd
0.1 1/h 8760 10,000,000 5.00 x 10
-10
0.75 1/h 8760 4,150,000 1.20 x 10
-09
3 1/h 8760 400,000 1.20 x 10
-08
AC15
5 1/h 8760 70,000 7.20 x 10
-08
1 1/h 8760 2,000,000 2.50 x 10
-09
DC13
3 1/h 8760 450,000 1.10 x 10
-08
2 1/h 8760 1,000,000 5.00 x 10
-09
AC1
4 1/h 8760 600,000 8.40 x 10
-09
11.2 Dimensional drawings
11.2.1 UE410-MU and UE410-GU main modules
11.2.2 UE410-XU, UE410-8DI, UE410-2RO, UE410-4RO, UE410-PRO, UE410-DEV,
UE410-CAN modules
Tab.
46
:
PFHd values
Fig.
50
:
Dimensional drawing
UE410-MU and E410-GU
(mm)
Fig.
51
:
Dimensional drawing
UE410-XU, UE410-8DI,
UE410-2RO, UE410-4RO,
UE410-PRO, UE410-DEV,
UE410-CAN (mm)
114.4
93.7
120.8
22.5
96.5
93.3
58
78
114.4
93.7
120.8
29
22.5
96.5
93.3
58
78
