Product description
3.6 UE410-MU/UE410-XU programs
The modules have 9 settable programs each that can be set via a rotary switch.
Up to two applications acting independently or two applications that are dependent on
each other (A and B) can be controlled. These can act independently or dependent on
each other, depending on the program (see Fig. 3-Fig. 6).
The program selection determines the type of safety sensor equipment to be connected
and the logic instructions.
Program Description
0 Module inactive
1-2
Input control circuit A is linked by means of OR logic to input control
circuit B and acts on all the safety outputs Q1-Q4.
3.1-3.2 • Input control circuit A acts on the safety outputs Q1, Q2, Q4.
• Input control circuit B is muting input and controls the muting lamp
via Q3.
4 Input control circuit AB acts on all the safety outputs AB (two-hand IIIC).
5-7 • Input control circuit A acts on both safety outputs Q1/Q2 and Q3/Q4.
• Input control circuit B acts only on the safety output Q3/Q4.
8 • Input control circuit A acts only on the safety output Q1/Q2.
• Input control circuit B acts only on the safety output Q3/Q4.
9 • Input control circuit A acts on both safety outputs Q1/Q2 and Q3/Q4.
• Input control circuit B acts only on the safety output Q3/Q4.
