SICK Flexi Classic series User Manual

Chapter 11 Operating instructions
Flexi Classic
96 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011509/YPP0/2015-10-26
Subject to change without notice
Technical specifications
11 Technical specifications
11.1 Data sheet
11.1.1 UE410-MU/UE410-XU modules
Minimum Typical Maximum
Supply circuit (A1, A2)
Supply voltage U
B
19.2 V DC 24 V DC 30 V DC
Type of supply voltage
PELV or SELV
The current of the power supply unit for the main
module has to be limited to a maximum of 6 A —
either by the power supply unit itself or by a fuse.
Residual ripple U
ss
– – 3 V
Power consumption – – 3 W
Maximum switch-on time – – 60 s
Short-circuit protection 4 A gG with tripping characteristic B or C
Input circuit (I1-I4, EN, S1-S3)
Number of inputs – – 8
Input voltage (high) 13 V DC – 30 V DC
Input voltage (low) –5 V DC – 5 V DC
Input current (high) 2.4 mA 3 mA 3.8 mA
Input current (low) –2.5 mA – 2.1 mA
Input capacitance 9 nF 10 nF 11 nF
Minimum switch-off time
10)
(I1/I2)
program 3.1, 7, 8
7 ms – –
Minimum switch-off time
10)
(I1/I2)
program 1, 2, 4, 5, 6, 9
20 ms – –
Minimum switch-off time
10)
(I1/I2)
pressure sensitive mat
20 ms – –
Minimum switch-off time
10)
(I3/I4)
program 1, 2, 7, 8, 9
7 ms – –
Minimum switch-off time
10)
(I3/I4)
program 4, 5, 6
20 ms – –
Minimum switch-off time
10)
(X1-I1/X2-I2) program 3.2
70 ms/20 ms – –
Minimum switch-off time (EN) 7 ms – –
Maximum break time of the input
signal without switching of the
outputs (Q1-Q4)
– – 1 ms
10)
Time without sensor, the data for the sensors connected apply in addition.
Tab.
39
:
Data sheet
UE410-MU/UE410-XU
