About this document
Symbol Sensors
Electro-mechanical safety switches
Emergency stop button
Electro-sensitive protective equipment (ESPE)
Sensors that can be tested (e.g. photoelectric switches)
Inductive safety sensors (e.g. IN4000)
Two-hand operating panel (IIIA)
Two-hand operating panel (IIIC)
Jog mode via two-hand operating panel (IIIA) (time limit 5 s)
Muting lamp and Reset required lamp (not monitored)
Lamp permanently ON: Muting active
Lamp flashing 1 Hz: Reset required
Pressure sensitive mats (4-wire system)
Reset button
Flexi Loop
Tab.
1
:
Sensor symbols
