3.4.5 Available input/output configurations
See the model name on the type plate for the interface configuration:
Fig. 32 Model name (example)
Complete description of the model name, see → p. 161, §9.6.
Table 4 Available input/output configurations
F6A - 4P 3D 08 - EA 1A - T218
I/O Configuration / Data Interfaces
Model
name
code
DO.0
Status
Output
1
DO.1
Status
Output
2
FO.2
Pulse
Output
1
FO.3
Pulse
Output
2
RS485.1 RS485.2 RS485.3 Ethernet AO
Analog
Output
Encoder HART
p/T
Modules
Intrinsically safe Version (Ex i)
1A x x x x x x x
1J x x x x x x x
2A x x x x x x x
Flameproof enclosure / increased type of protection
(Ex d / e)
1B x x x x x x x x
1D x x x x x x x x
1E x x x x x x x x
1L x x x x x x
2B x x x x x x x
2D x x x x x x x x
2E x x x x x x x x
