4.2.5 Menu structure
The following Table shows an overview of the menu structure on the display.
Table 12 Menu structure
Menu item Significance
Standard display 1 Configurable display page
Standard display 2 Configurable display page
Device status Device status
Current events Current events overview
Current event list Current events list
Event summary Event history overview
Event summary list Event history overview
Last event reset History events reset timepoint
Measurement values Meter measured values
+V and -V Volume at flowing conditions, uninterrupted
+Ve and -Ve Volume at flowing conditions, interrupted
+Vt and -Vt Volume at flowing conditions, total
Q and VOG Flow rate and gas velocity
VOG and SOS Gas velocity and sound velocity
P(i) and T(i) Pressure and temperature for internal measured value correc-
tion
P(e) and T(e) Pressure and temperature for volume conversion
FO and AO Pulse frequency and analog output value
Volume conversion
[1]
[1] Only visible in configuration with integrated EVC
Volume conversion (only visible when option active)
+Vb and -Vb Volume at base conditions, without errors
+Vbe and -Vbe Volume at base conditions, with errors
+Vbt and -Vbt Volume at base conditions, total
+M and –M Mass, without errors
+Me and -Me Mass volume, with errors
+Mt and -Mt Mass total
Qb and mf Standard flow rate and mass flow rate
P and T Pressure and temperature for volume conversion
C and K Conversion factor and compressibility
Z and Zn Real gas factors for operation and standard state
Device Information Electronics type plate
Measuring point Measuring point identifier
SN device Device serial number
SN electronics Signal Processing Unit electronics serial number
SN meter body Meter body serial number
Firmware version Firmware version
Firmware CRC Firmware checksum
Firmware date Firmware release date
Metrology CRC Checksum for metrological parameters
Min. oper. pressure Minimum operating pressure
Max. oper. pressure Maximum operating pressure
Impulse factor Impulse factor
