SICK FLOWSIC600-XT - Remove the Backup Battery; Insert the New Backup Battery

108 FLOWSIC600-XT · Operating Instructions · 8018846/1BHP/V2-1/2021-05 · © SICK Engineering GmbH
Maintenance
Subject to change without notice
5.3.3.2 Remove the backup battery
5.3.3.3 Insert the new backup battery
1 Make sure the external power supply
is active.
2 Disconnect the backup battery
connection.
3 Take the backup battery out of the
holder.
1 Unpack the new backup battery and check for transport damage.
2 Do not use the backup battery when any damage can be seen.
3 Make sure the external power supply
is active before connecting the
backup battery. Otherwise the
backup battery is immediately active.
4 Insert the backup battery in the
holder and connect to the “Backup
Battery” connection.
