Installation
Subject to change without notice
3.4.8 Connection parameters of inputs and outputs
3.4.8.1 Safety-relevant parameters Ex-i
Table 5 Safety-relevant parameters Ex-i
NOTICE:
The FLOWSIC600-XT with intrinsically safe inputs and outputs (Ex ia version)
contains a shunt Zener diode barrier. Grounding the FLOWSIC600-XT must
satisfy the requirements for grounding intrinsically safe power circuits in
compliance with IEC 60079-14.
For intrinsically safe installation of FLOWSIC600-XT measurement devices,
SICK recommends the use of the SICK FLPS multibarrier as multi-channel
supply and input isolation amplifier.
Part Nos.: 2098122 and 2098136 (with Ethernet)
For more information, see the “SICK FLPS Multibarrier” Operating Instructions
Model name code Safety-relevant parameters
according to ATEX/IECEx
Safety-relevant parameters
according to CSA
1A
→ Fig. 63, → p. 132 → Fig. 72, → p. 141
1J
→ Fig. 64, → p. 133 → Fig. 73, → p. 142
2A
→ Fig. 65, → p. 134 → Fig. 74, → p. 143
